THROTTLE BODY

THROTTLE BODY
1
90641001044
THROTTLE BODY CPL.
2
90641023000
FUEL INJECTOR
3
90141001001
INJECTOR CLIP
4
90141023004
CONNECTOR FUEL RAIL
5
90141023005
Vis (spec)
6
90141023002
CABLE SUPPORT
7
90141023003
Damper
11
90508006004
SOCKET HEAD BOLT M6X1X8
12
90514030000
BRACKET ECU R/S
13
90514029000
BRACKET ECU L/S
14
J991060203S
COUNTERSUNK SCREW M6X20
15
90141002006
O-RING CONN. FL. CYL.-THR.BODY
16
90641002300
CONN. FLANGE CYLINDER-THR.BODY
17
90641072000
IDLE ADJUSTER
18
90141072001
O-Ring
19
90141070000
THROTTLE POSITION SENSOR
20
90141070001
Vis (spec)
21
90141071000
TMAP-SENSOR
22
90141071001
Vis (spec)
23
90641002010
Collier
24
J005040081
FLAT HEAD SCREW M4X8 PH
99
90141031100
ECU RAW PART

Узлы для RC 200 WHITE W/O ABS CKD 16 (F5142P1) [AR] KTM
