TANK, SEAT|Frame|07

TANK, SEAT|Frame|07
Например: 28507013099
1
28507013099
FUEL TANK CPL.
2
69007027000
rubber grommet, tank mounting
3
61007065000
collar bushing, front tank holder
4
77307040041
Isolation pad
5
28515023000
Reducer GRS8-6
6
0025080306
Vis
7
0024060156
Vis
8
31008060000
rubber grommet D=8mm open
9
0912080403
SHCS DIN 912 M8x40
10
6100716000001
BEARING SLEEVE, EXTERNAL
11
77407011000
screw, seat M5
12
28007040000
Saddle assy
13
21007008151
gasket tank insert
2 024 ₽/шт
14
28507008060
GASKET, UPPER TANK INSERT
15
47106003160
quick release rubber grommet
16
28508057000CCA
OVER, IGNITION LOCK
17
014580060451
Cap hd. screw ISO 14580-M6x45-10.9 black
18
28508057010
BUSHING, IGNITION LOCK COVER
19
014579050301
Vis
21
28507059000
RUBBER GROMMET, IGNITION LOCK
22
28508058020
RUBBER GROMMET, ADAPTER
23
45239060050
COLLAR BUSHING 6,3X8X13X9,5
24
28508058000
TANK SPIDER
25
28503002010
rubber support
26
28507050050
SEAT LEVER ASSY
27
0738060181
BHCS ISO 7380 M6X18
28
60015025100
Y-CONNECTING PIECE YS 6-6-6 06
29
014579050081
Vis
30
28512010000
PASSENGER GRIP
31
28012010000
LUGGAGE CARRIER
32
28507040030
RUBBER GROMMET, SEAT COVER
33
28007047000
PILLION SEAT
34
83008000012
Vis (spec)
36
28012010010
COLLAR BUSHING
37
58605083014
Vis (M5x14)
38
0019050121
COUNTERSUNK SCREW ISA25 M5X12
39
28515024001
Hose 8x13 FKM/ECO
40
78015019001
Hose epa d=6/10 per meter
