SWING ARM » SWING ARM

SWING ARM » SWING ARM
Например: 37010151B
1
37010151B
SWING ARM
2
36911172A
XLE, REAR SWING ARM
3
85210011B
. THRUST WASHER 20.5X36X1.8 MM
3
85210021A
pc - Rondelle (0,2 mm)
3
85210031B
Rondelle
4
77151578B
Vis
5
763110N01
ut
6
74140621A
Collier
7
88440071A
pc - . SPRING RING
8
37310091B
SLIDING BLOCK
9
44610011A
CHAIN GUARD
10
77910242A
Vis (M8x90)
11
067092190
5 pc - Rondelle (10.5x15x2)
12
37310081A
COVER
13
36520381A
SHOCK-ABSORBER
14
85610642A
Rondelle
15
77210551A
pc - Vis (M5x0.8x16)
16
85350071A
Rondelle (spring)
17
77151598C
2 pc - Vis
18
77910501A
Vis
19
44710181BB
Guard chain sliding shoe
20
938230128
pc - O-Ring
21
036499710
Gasket (NYLON)
22
67640362A
. CHAIN 620 S/03
23
37310191A
PLATE
24
77150048B
pc - Vis (M3x8)
25
87210191A
.PLUG
26
77910091A
pc - Vis (M5X12)
27
43311081F
STICKER, ADJUSTING CHAIN
27
43311081H
STICKER, ADJUSTING CHAIN
28
56510111A
Garde-boue arrière
29
77911191B
Vis
30
85210791B
pc - Rondelle
31
81910211A
REAR WHEEL SPINDLE (Rear)
32
74811171AA
Nut
33
067077320
Rondelle
