SIDECAR FENDER

SIDECAR FENDER

Например: 2604

1

2604

Vis

2

3560WA

BOLT, TEE

3

3561WC

BOLT, TEE

4

4721

SCREW HEX CAP

5

6653A

Rondelle

6

7118

Rondelle

7

7130W

Rondelle (Lock)

8

7601

NUT, FLANGE LOCK

9

7624

NUT, SELF LOCKING HEX

10

7629

NUT, KEPS 10-32

11

7638

Nut

12

7823

Nut

13

10006

CABLE STRAP

13

10065

CABLE STRAP

14

11410

Damper

15

53439-79

BULB

16

LAMP ASSEMBLY, fender tip

17

59180-80

LENS, FENDER TIP, (FRONT)

18

GASKET, fender tip lamp lens

19

59211-74A

TRIM, FENDER, FRONT

20

59255-91

FRAMED RED REFLECTOR

21

WIRING HARNESS, w/ 22-33

22

PLUG, four terminal

23

72037-71

HOUSING

24

72038-71A

SOCKET, TERMINAL

25

72039-71A

PIN TERMINAL

26

CONNECTOR, six pin

27

72044-71A

SINGLE POS. PLUG HOUSING

28

PLUG RECEPTACLE

29

PROTECTIVE PLUG (w/ sidecar removed)

30

72275-74

TAB,COM,2-TERM

31

74521-77A

TERMINAL PLUG, 3 POSITION

32

74536-77A

CONTACT PIN

33

SOCKET, single pin

34

71795-63A

REGULATOR CABLE CLAMP

35

FENDER, sidecar (prime)
