SHOCK ABSORBER DISASSEMBLED

SHOCK ABSORBER DISASSEMBLED
Например: 46181018S1
1
46181018S1
MONOSHOCK CASE CPL.
2
50180213S15
DCC COMPR.DAMP.CON. SX 12 LINK
3
50180217
O-ring 27x1,5 Viton70 green ISO 3601-3S
5
R12012
Ball joint bearing kit top 12mm
6
46181105
Distance bush 12x15/18,5/24,5x10,5
7
52000149
Sticker WP Warning Indien Bike 60 x 35mm
8
50180095
HS cylinder-head screw R1/8 l8
9
46810893
O-ring 5,28x1,78 NBR70 black
10
36120151
HS lock screw M5x6
11
46811208
Rubber cap do not open 22x5,5 NBR
12
46181014
Clamp d61
13
0912050203
AH SCREW DIN0912-M 5X20
14
46181013
Spring retainer M55x2x71x35 plastic
15
50180410
Washer 58,6x73,6x1,5
16
91010324S
PRING 55/63/71 N/MM SET
16
91010323S
PRING 58/66/74 N/MM SET
16
91010311S
pring 66 N/MM SET
17
46180349
Spring retainer 28x56x15
18
46180356
PISTON ROD NUT M10X1
19
14460016
Piston 10,05x35,5x13,7 3,5/5,5
20
46181016
Bush 10x17x10
21
46810474
Piston rod nut M12x1
22
46811258
Washer 12x24x2,5
23
46811206
Piston ring 43,95x45,95x8
24
46810035
O-ring 37x,82x1,78 Viton70 green
25
46810560
Piston 12,05x45,5x12,6 4,5/7
26
14460017
Rebound disc 12x35x4 h0
27
46180669S
ealholder 46x28 cpl.
28
46810010
Round-wire snap ring 49x1,8
29
46180338
Cover 46,12x6,2 h15,7
30
46180365
Rubber pad 17,2x45,2x30 black
31
46180520S4
MONOSHOCK LOWER PART
32
50180751S1
HOCK ABSORBER FLUID 5 LT
