SHOCK ABSORBER DISASSEMBLED

SHOCK ABSORBER DISASSEMBLED
Например: 46811525
1
46811525
SHOCK ABS. BOTTOM L=46
2
36120586S
PISTON ROD D=14, L=126
3
46811401S
NEEDLE CPL. D=4, L=142
4
46811222
O-RING 36X0,5
5
46811263
Rondelle
6
46811261
PIN 4X35
7
46811262
ADJ. KNOB D=41
10
46811221
Shaft seal 29x35x3
11
46811367
INTERMEDIATO RING H=4
12
46811268
CIRCLIP 22X1,2
13
46811259
NEEDLE SEAT 5X17,25
16
46811076
ADAPTOR BUSH KGW 10X20
17
46811027
Ball joint bearing 15x25x13
18
46811077
ADAPTOR BUSH KGW 10X22
19
46811050
SEAL KGW
22
36120135
BUMP RUBBER WP65 RED
23
36120650
SCREW CAP M37,65 STEEL
24
46811044
DUST SEAL 1424
25
36120064
O-ring 29,74x3,53 NBR70
26
36120522S1
ADAPTER CPL. D=36 H=20,5
27
36120469
SHIM 28,5X14X2
30
36120726
SHOCK ABSORB.CASE PGB KGW H=33
31
0770380020
O-RING 38,00X2,00 NBR 70 SH
32
36120137
TUBE L=167
33
36120019
Bush M40x1xM44x1,5x70
34
36120467
PROTECTION SLEEVE L=40
41
36120015
Lock nut shock M44x1,5
42
36120418
Adjustment nut shock M44x1,5
43
40540015
Round-wire snap ring 38x1,5
45
46810893
O-ring 5,28x1,78 NBR70 black
46
36120151
HS lock screw M5x6
47
93010049
SPRING WP 40-220
47
93010050
SPRING WP 45-220
48
36120386
Spring retainer 27x57x2
49
46811208
Rubber cap do not open 22x5,5 NBR
50
50180751S1
HOCK ABSORBER FLUID 5 LT
60
36120557
REBOUND BUSH H=5,6
62
36120312
SHIM 10X16X0,30
62
36120334
SHIM 10X21X0,20
62
36120335
SHIM 10X23X0,20
62
36120336
SHIM 10X25X0,20
62
36120337
SHIM 10X27X0,20
62
36120330
SHIM 10X29X0,15
62
36120331
SHIM 10X31X0,15
62
36120332
SHIM 10X33X0,15
62
36120329
SHIM 10X27X0,15
62
36120325
SHIM 10X19X0,15
62
36120340
SHIM 10X33X0,20
68
36120314
SHIM 10X18X0,30
68
36120342
SHIM 10X21X0,25
68
36120343
SHIM 10X23X0,25
68
36120336
SHIM 10X25X0,20
68
36120284
SHIM 10X16X0,10
68
36120335
SHIM 10X23X0,20
68
36120328
SHIM 10X25X0,15
75
36120071
Piston 10,5x35,6x13,65 3,5/5,5
77
36120040
Pistonring 33x35x8
78
46811267
BUSHING 6X9X3
79
46811251
BLEED SCREW M 4X6
80
36120604
Washer 10x22x2,5
81
40540450
Shim 6x9,5x0,30
82
40540403
Shim 6x18x0,10
83
36120605S2
PISTON ROD NUT CPL. H=15,2
85
36120631
RESERVOIR SCREW L=98 GREY
86
36120024
Piston 42mm reservoir
87
36120466
O-ring 32x5 Viton70
88
46810022
Piston ring 36,5x39,5x3,9
89
36120552
SCREW FOR RESERVOIR CAP M5
90
46810850S7
CC-COMPRE.DAMPING CONTROL CPL.
91
46810334
Rondelle (Lock)
92
46810333
STEEL-BALL D=4,75
93
50180131S
ADJUSTING KNOB CC-MECH. CPL.
94
50180095
HS cylinder-head screw R1/8 l8
