SHOCK ABSORBER DISASSEMBLED

SHOCK ABSORBER DISASSEMBLED
Например: 1200Y002
1
1200Y002
PA cpl. KTM LC8
2
50180366
Bearing bush 14x15/18/24,5x10,45
3
46180003
Seal ring 19,5x26x3
4
50180168
Round-wire snap ring 25x1
5
50180005
Ball joint bearing 15x25x13
6
50180213S4
Compression cpl.
7
48600058
Cross flat head screw M4x6
8
48600009
O-ring 3,7x1,6 NBR70
9
50180095
HS cylinder-head screw R1/8 l8
10
46810016
O-ring 48x2 NBR70 siliconized
11
50180237
RESERVOIR SCREW L=123,5 D=52
12
52000086
Sticker WP clear 35x55
13
46180014
O-ring 41x5 Viton75
14
46180002
Piston 52mm reservoir
15
46180015
Pistonring 47,5x50,5x3,9
16
50180344
RESERVOIR CAP D=58
17
46810893
O-ring 5,28x1,78 NBR70 black
18
36120151
HS lock screw M5x6
19
46811208
Rubber cap do not open 22x5,5 NBR
21
35480083
O-ring 10x2 NBR70 siliconized yellow
22
40540440
Steel ball d5
23
46810332
Spring (3,2) 17
27
46810003
O-ring 17x3 NBR70 siliconized
31
48600044
O-ring 6x1,5 NBR70
32
50180381
Adjuster PA black
33
46811771
Hs flat head screw m5x10
34
50180370
Washer 64,6x70x1,4 support ring
35
50180369
O-ring 63,09x3,53 NBR70
36
50180371
PA outside ring 58,13/70x61,4/78x45
37
50180372
O-ring 57,15x3,53 NBR70
38
50180373
Washer 58x63,4x1,4 support ring
39
50180097
O-ring 52x2 NBR70
40
50180177
Springwasher 8,2x16x0,6
41
50180300
Needle 10,2x37
42
50180271
SCREW CAP M20x1, D=11
43
50180367
Tube 50x180 PDS
44
50180133
CIRCLIP 50X1,5
45
50180081
Spring guide 54,15x60x40
46
50180114
Intermediate washer spring 61,7x78x1,5
47
91210022
SPRING 140-265 (62) D=15,0
47
91210028
SPRING 140-255 (62) D=15,0
48
50180402
INTERM.RING SPRING RET. H=3,5
49
50180273
Round-wire snap ring 58,5x2
50
50180352
O-ring 66,27x1,78 Viton70
51
50180463S
PRING RET. D=80 W. O-RING 05
52
50180141
Piston rod nut 16x1
53
50180210
Washer 16x21x1
53
50180209
Shim 21x36x0,25
53
50180054
Shim 16x28x0,2
54
50180099
O-ring 44x,17x1,78 Viton70
55
50180197
Piston 16,05x49,6x13,5 4,5/7
56
50180135
Piston ring 47,95x49,95x8
57
50180074
SHIM 16X32X0,30
57
50180075
SHIM 16X34X0,30
57
50180076
SHIM 16X36X0,30
57
50180068
SHIM 16X38X0,25
57
50180069
SHIM 16X40X0,25
57
50180070
SHIM 16X42X0,25
57
50180062
Shim 16X44X0,20
58
50180269
SANDWICH BUSH D25XD16X14,5/D
59
50180047
Shim 16X32X0,15
59
46811637
Shim 32,25x36x0,30
59
50180008
SHIM 16X22X0,10
59
50180058
Shim 16x36x0,20
59
50180057
Shim 16x34x0,2 y5
59
50180056
Shim 16x32x0,2
59
50180035
Shim 16x21x0,30
60
50180311
Piston 16x49,6x13,5
61
50180036
Shim 16x22x0,30
61
50180064
Shim 16x30x0,25
61
50180065
SHIM 16X32X0,25
61
50180066
SHIM 16X34X0,25
61
50180058
Shim 16x36x0,20
61
50180059
SHIM 16X38X0,20
61
50180069
SHIM 16X40X0,25
61
50180070
SHIM 16X42X0,25
61
50180071
SHIM 16X44X0,25
62
50180161
SHIM REBOUND H3 '99
62
50180401
SHIM REBOUND H16 '03
63
50180200
BUSH M8X1
64
50180157
O-ring 7x1,5 Viton70 green
65
50180201
NEEDLE SEAT M8X1
66
50180363
Tube 5,5x138
67
48600049
O-ring 8x2 NBR70
68
50180279
Bush 5/8,2/7x9,5/16,8x23
69
50180364
Needle 4x161
70
46811265
O-ring 2,2x1,6 Viton75 green
71
50180362
PISTON ROD D=18 M16X1
72
50180349S1
ADAPTOR CPL. D=50, H=28,5
73
50180107
Rubber pad rebound 27x48x8 NBR80
74
50180304
STEEL DISC 18,5X43,7X6
75
50180102
Washer 18x22,5x1,5 plastic
76
50180101
X-ring 18x2,62 Viton70
77
50180349
ADAPTOR D=50, H=28,5
78
50180103
O-ring 41x5 NBR70
79
46180119
Guide bushing 18x20x12
80
50180082
Dirt scarper 18mm
81
50180126
Round-wire snap ring 53x1,75
82
50180211
CAP D=50
83
50180276
Rubber pad 17,2x45,2x40 black
84
50180283
HH locking nut M18x1 h5 WAF24
85
50180358
Footpart M18x1 h54 natural
86
50180365
Bearing bush 14x16/21,8/29x14
87
50180159
Seal ring 22x32x4
88
50180175
Round-wire snap ring 32x1
89
50180179
Ball joint bearing 16x32x21
90
50180281
HH screw M14x9
91
50180222
O-ring 4x1,5 NBR70
92
50180280
ADJUSTING SCREW 80 DEG., L=39
93
48600522
CATCH SPRING D=2,9 L=4,6
94
40540603
Steel ball d3
98
50180751S1
HOCK ABSORBER FLUID 5 LT
99
R12008
EPAIR-KIT GASKET 5018 PDS 03
