SHIFTING MECHANISM|Engine|34

SHIFTING MECHANISM|Engine|34
Например: 0024060156S
1
0024060156S
Vis
2
63534015000
Shift locker cpl.
3
0625068070
deep groove ball bearing 6807
4
0019050121S
Vis (Torx)
5
63534011200
Bearing retaining bracket
6
63534012001
shift drum 6G
7
0625068060
Roulement (6806 C3)
8
79234012020
MAGNET HOLDER CPL.
9
79211023000
GEAR SENSOR
10
0984050123S
CYLIND. SCR. DIN6912 M5X12 8.8
11
0025060166S
Vis
12
63533022000
bearing retaining plate
13
63534005033
shift shaft cpl.
14
56534013100
TENSIONING SPRING 0,8MM
15
54634020000
SPRING GUIDE
16
61234014000
RETURNSPRING 2MM
17
54634050000
STOP DISK 14X30X1
18
54632095000
Needle bearing (14x20x12)
19
0760142460
radial shaft seal 14x24x6 B
20
0007025241
Dowel pin
21
63534050000
magnet holder
22
63534050010
wave spring Smalley SSB-0075-S17
23
0988142005
Thrust washer DIN 988 14x20x0.5
24
0471140100
Rondelle (Lock)
25
6413403000033
Pull Rod
26
50233041500
Rondelle (Lock)
27
63534051000
Shift assistant sensor
28
0025060166S
Vis
29
63534024000
detent arm cpl.
30
63534052000
step washer
31
63634023000
Detent arm spring
32
63534002000
shift fork 5-6 gear
33
63534001100
Shift fork
34
75034019100
SHIFTRAIL
35
0402080200
needle roller D8x20
36
63534036044
Shift rod cmpl.
37
0738060205S
Oval head screw ISR M6x20-A2-70-MK
39
014579080301S
screw ISO 14579-M8x30-10.9-MK black
40
54310086200
Nut (M8x10,9)
41
6353403104433
Gear shift lever preassembled black
42
54634032100
SHIFTING LEVER SPRING 250
44
54634031050
BOLT 6X25 FOR SHIFT LEVER
45
0625006087
GROOVED BALL BEAR. 608 2RS C3
