SHIFTING MECHANISM|Engine|34

SHIFTING MECHANISM|Engine|34
Например: 50334001200
1
50334001200
SHIFTING FORK 5TH/6TH GEAR
2
50334002200
SHIFTING FORK 2ND/4TH GEAR
3
50334003200
SHIFTING FORK 1ST/3RD GEAR
5
50334005100
SHIFTING SHAFT CPL.
6
50334007052
SPRING FOR RATCHET 0,5X11,5
7
50334007000
RATCHET SUPPORT 125/200'98
8
50334007054
STOP DISK 8,2X26X0,7
9
50334007053
BUSHING 6X8X12X4,5
10
50334007150
SHIFTING RATCHET 125/200
11
50334007051
PRESSURE END PAD 4,1X5,6X8,4
12
50334012300
SHIFTING DRUM 06
13
50334013000
LOCATING DRUM 125/200'98
14
50334014000
RETURN SPRING 3MM
16
50334016000
Vis (spec)
17
50334017000
SHIFTING GATE 3MM 125/200'98
18
0402061000
NEEDLE ROLLER ZRB 6X10
19
50334019000
SHIFTING ROD DRIVE 11,8X67,5
20
50334020000
SHIFT. ROD DRIVE END 11,8X94,5
23
50334023000
LOCATING LEVER SPRING 2,5MM'98
24
50334024144
LOCATING LEVER CPL. 08
29
0625060006
Roulement (6000 RS1 C3)
30
0625618050
Roulement (61805 C3)
31
0991050102
FLAT H.SCEW DIN7991-M5X10 10.9
32
0472260120
LOCK RING DIN0472-26X1,2
33
0093251209
SPRING WASHER 12,2X25X0,9
34
0402040980
NEEDLE ROL.DIN5402 NRB 4X9,8
35
54632095000
Needle bearing (14x20x12)
36
49033031000
STOP DISK 14,3X20X1
37
0471140100
Rondelle (Lock)
38
49033031015
STOP DISK 14,2X22X1,5
39
0760142460
radial shaft seal 14x24x6 B
40
0024060156S
Vis
41
50233041500
Rondelle (Lock)
42
0025060166
Vis
43
0125080003
Rondelle
44
0349000050
WASHER DIN7349-5X15X2
45
0025050206
Vis
52
54634052300
SLEEVE FOR LOCKING LEVER
54
54734031000
Gear change pedal
56
54634032100
SHIFTING LEVER SPRING 250
57
54634031050
BOLT 6X25 FOR SHIFT LEVER
58
54634131000
STEP PLATE FOR SHIFT LEVER 250
