RIGHT REAR WHEEL

RIGHT REAR WHEEL
Например: 64111-38F32
1
64111-38F32
Hub,rear,r
2
65310-38F00-YL8
Rim,rr.wheel
2
65310-38F30-YL8
Rim comp,rr whe
3
09140-10021
Nut
4
09164-18004
Rondelle
4
64723-38F00
Washer,hub
5
09141-20006
NUT, HUB
5
09141-18010
Nut
5
09141-18008
Nut
6
04111-4040A
PIN
820 ₽/шт
7
54725-09F01
Cap,wheel cente
8
64711-38F10
AXLE,REAR,R (Rear)
8
64711-38F20
Axle,rear,r (Rear)
9
64120-38F00
Drum,rear brake
10
09280-10016
КОЛЬЦО УПЛОТНИТЕЛЬНОЕ РЕЗИНА
162 ₽/шт
11
09161-10007
Rondelle
12
09247-10001
Заглушка масляного дренажа
1 560 ₽/шт
13
64210-38F00
Panel,rear brak
14
09280-63001
O-Ring
15
09364-04004
Болт соединяющий
7 820 ₽/шт
16
64400-38830
Shoe set,rear b
17
55420-30000
SPRING
221 ₽/шт
18
64440-09F00
Cam comp,rear b
19
09106-08161
BOLT(8X20)
2 270 ₽/шт
20
O RING, PANEL
21
64123-38F00
Cover,rear brak
22
01547-0612B
БОЛТ
82 ₽/шт
23
64124-38F00
Seal,rear brake
24
64443-18A00
O-ring,bk cam d
25
09160-16033
Шайба
2 310 ₽/шт
26
64451-09F00
Lever,rear brak
27
01550-0635A
Болт
102 ₽/шт
28
08316-1006A
Гайка
85 ₽/шт
29
64484-38F00
Spring,rr brake
30
TIRE, REAR [MODEL K4/K5/K6/K7, P17, ->5110-38F21]
30
TIRE, REAR [F.NO.5SAAK46A3X102001~, P24]
30
TIRE, REAR [F.NO.5SAAK46A3X102001~, P17]
31
43130-24A00
Ниппель
468 ₽/шт
32
09352-40706-00B
Hose(4X7X2000)
1 087 ₽/шт
33
09401-06405
Хомут
119 ₽/шт
34
09407-03401
CLAMP(L:33)
97 ₽/шт
35
09408-00200
ХОМУТ МАЛЫЙ
1 370 ₽/шт
