Главная Каталог товаров KTM EPC 2016 KTM Offroad KTM 2016 MX KTM 2016 Offroad 350 SX-F (F8201P5) [EU] KTM (VIN: VBKSXP43) REAR WHEEL

REAR WHEEL

REAR WHEEL

Например: 7901000134430

1

7901000134430

REAR WHEEL CMPL. 2.15X19''DID

2

25010010144

REARHUB CPL.

3

77710011000

BEARING DISTANCE TUBE 121,5MM

4

0625060058

Roulement

5

0472047175

CIRCLIP DIN0472-47X1,75

6

0760324771

Joint

7

77710016000

DISTANCE BUSHING REAR WHEEL

8

7901007120530

Spoke M4,5X205-19 Black 16

534 ₽/шт

9

77109072000

SPOKE NIPPLE M4,5 AL 11

10

7911007000030

RIM 2,15"X19" EXCEL BLACK

32 361 ₽/шт

11

79010060000

BRAKE DISC REAR 220MM 16

12

59009062013

Vis (spec)

13

50310073200

RIM BAND 18'' AND 19''

16

77710015000

DISTANCE RING

19

7771015104801

Rear Sprocket 48-T

6 442 ₽/шт

19

7771015105001

Rear Sprocket 50-T

6 442 ₽/шт

19

7771015105201

Rear Sprocket 52-T

6 215 ₽/шт

21

0019080266S

Vis (M8x26)

22

06923080003

Nut

23

50310165118

CHAIN 5/8X1/4'' MX

24

50310166000

CONNECTING LINK F. 50310165118

33

78110090200

Tyre locker 2,15"

34

77110090050

NUT FOR WHEEL HOLDER

38

55003135000

PLUG FOR RIM

40

77710085044

WHEEL SPINDLE CPL. '13

41

77710084000

CHAIN TENSIONER R/S

42

50304040100

screw M10x1.25x50 WS10

43

58414030000

Nut (M10x1,25)

44

61010086000

COLLAR NUT M25X1,5 WS=32 05

97

77710015010

REAR WHEEL REP. KIT

98

SPAA13U50AM1186

drivetrain kit SX 13T/50T

99

00050000975

SPOKE KIT REAR '19' BLACK
