REAR WHEEL

REAR WHEEL
Например: 76210001044
1
76210001044
REAR WHEEL RALLY CPL.
2
7531001004491
Rear Wheel Hub Cpl
36 942 ₽/шт
3
75310011000
BEARING SPACER TUBE L=106MM 07
4
0625062052
GR.BALL BEAR. 6205-2RSHC3HMTF7
5
0472052200
CIRCLIP DIN0472-52X2
6
0760305271
SHAFT SEAL RING 30X52X7
7
60110013000
SPACER BUSH. REAR WHEEL R/S 06
8
60010015000
SPACER RING 03
9
7621007000030
RIM 2.50X18''
10
75310072217
SPOKE M5X217-17G 18'' DACRO
11
75310172207
SPOKE M5X207-27G 18'' DACRO
12
60310072100
SPOKE NIPPLE QUADRAX M5
14
50310075100
TUBE 110/100C-18
15
50310073200
RIM BAND 18'' AND 19''
20
5841005104404
Rear sprocket orange 44-t
12 909 ₽/шт
20
5841005104604
Rear sprocket orange 46 t.
12 909 ₽/шт
20
5841005104804
Rear sprocket orange 48-t
12 909 ₽/шт
20
5841005104904
Rear sprocket orange 49-t
12 909 ₽/шт
20
5841005105004
Rear sprocket orange 50-t
12 909 ₽/шт
20
5841005105104
Rear sprocket orange 51-t
12 909 ₽/шт
21
0019080266S
Vis (M8x26)
22
54310086200
Nut (M8x10,9)
23
7501005004491
Sprocket support cpl. silver
24 457 ₽/шт
24
60110012000
SPACER BUSH. SPROCKET SUPP. 06
25
60110016000
NILOS RING 6006AV
26
0625060060
Roulement (6006 DDU2CG23S6NM)
27
60110014000
SPACER BUSH. SPR. SUPP. IN. 06
28
54610459000
Damper - rear wheel hub
29
60010060000
Disque de frein
30
59009062013
Vis (spec)
32
76210081044
WHEEL SPINDLE REAR CPL. (Rear)
33
60010084000
CHAIN TENSIONER R/S LC8 03
34
60010086000
COLLAR NUT WH. SPINDLE REAR 03
35
58414030000
Nut (M10x1,25)
36
50304040100
screw M10x1.25x50 WS10
37
78010267118
CHAIN DID 118 LINKS
38
78010266100
RIVETING LINK FOR 78010167118
39
50210086000
COVERING CAP SFL16
40
56410100100
RIM LOCK VM4 (2.50'')
41
50310090050
NUT FOR WHEEL HOLDER '96
99
75010015000
REAR WHEEL REP. KIT
