Главная Каталог товаров KTM EPC 2013 KTM Offroad KTM 2013 MX KTM 2013 Offroad 450 SX-F FACTORY EDITION (F8475M1) [US] KTM REAR WHEEL

REAR WHEEL

REAR WHEEL

Например: 7711000114430

1

7711000114430

Rear Wheel Cpl. 2,15X19 Fact

101 126 ₽/шт

2

25010010144

REARHUB CPL.

3

77710011000

BEARING DISTANCE TUBE 121,5MM

4

0625060058

Roulement

5

0472047175

CIRCLIP DIN0472-47X1,75

6

0760324771

Joint

7

77710016000

DISTANCE BUSHING REAR WHEEL

8

77110071205

SPOKE M4,5x205-19'' 11

9

77109072000

SPOKE NIPPLE M4,5 AL 11

10

7911007000030

RIM 2,15"X19" EXCEL BLACK

32 361 ₽/шт

11

77310060000

Disque de frein

12

59009062013

Vis (spec)

13

50310073200

RIM BAND 18'' AND 19''

15

00050000917

SPOKE KIT REAR ''19''

16

77710015000

DISTANCE RING

19

5901005104204

Rear sprocket 42t orange

10 058 ₽/шт

19

7771095104504

SPROCKET 45-T

19

7771095104804

SPROCKET 48-T

10 058 ₽/шт

19

7771095104904

SPROCKET 49-T

19

7771095105004

SPROCKET 50-T

19

5901005105104

Rear sprocket 51t orange

10 058 ₽/шт

19

7771095105204

SPROCKET 52-T

21

0019080266S

Vis (M8x26)

22

06923080003

Nut

23

50310165118

CHAIN 5/8X1/4'' MX

23

78910065118

CHAIN 520 GPXV GOLD

24

50310166000

CONNECTING LINK F. 50310165118

24

78910066000

CONNECTING LINK F. 78910065118

33

78110090200

Tyre locker 2,15"

34

77110090050

NUT FOR WHEEL HOLDER

38

55003135000

PLUG FOR RIM

39

50210086000

COVERING CAP SFL16

40

77710085044

WHEEL SPINDLE CPL. '13

41

77710084000

CHAIN TENSIONER R/S

42

50304040100

screw M10x1.25x50 WS10

43

58414030000

Nut (M10x1,25)

44

61010086000

COLLAR NUT M25X1,5 WS=32 05
