REAR WHEEL

REAR WHEEL
1
5651000184490
Null
1
5651000194490
* REAR WHEEL 2,50-18"DID '93
2
5461001004490
Null
3
56510011000
BUSHING SPACER TUBE 121,5 MM
4
0625060058
Roulement
5
0760324771
Joint
6
0472047175
CIRCLIP DIN0472-47X1,75
7
78010016000
BUSHING FOR HUB 08
8
54610071000
SPOKE M5X207-10G 19''
8
50310071197
SPOKE M5X197-10G 18'' DDE
9
50210071700
SPOKE M5X211-10G
9
50310071197
SPOKE M5X197-10G 18'' DDE
10
56510070200
REAR RIM 2,50X19" EXCEL
10
56510070300
REAR RIM 2,50X18" DID
11
60310072200
Spoke nipple Quadrax M5 (M5)
15
58010060600
Disque de frein
16
0984060203
AH SCREW DIN6912-M 6X20 8.8
17
56509064000
SELF LOCKING NUT M6
20
7771015105201
Rear Sprocket 52-T
6 215 ₽/шт
20
58310151040
REAR SPROCKET 40-T
20
7771015104501
New Genuine Part
6 215 ₽/шт
20
7771015104801
Rear Sprocket 48-T
6 442 ₽/шт
20
7771015105001
Rear Sprocket 50-T
6 442 ₽/шт
21
0019080266S
Vis (M8x26)
22
54310086000
Null
23
50010065000
Null
23
50010065001
* CHAIN /M 5/8X1/4" PER METRE
23
53010065001
* O-RING CHAIN 5/8X1/4 PER MET
24
50310166000
CONNECTING LINK F. 50310165118
24
53010066000
MASTER LINK 5/8X1/4'' O-RING
30
52010073000
Null
31
50310075100
TUBE 110/100C-18
31
54610075000
Null
32
50210074500
* tyre 140/80-18" 70r mce
32
54610074300
* tyre 110/90-19" 62m d 701
33
56410100100
RIM LOCK VM4 (2.50'')
40
50210085044
Wheel spindle rear cpll=264mm
41
56510084000
% chain tensioner 125/500
42
0933080404
HH SCREW DIN0933-M 8X40 INOX
43
0934080003
Nut
44
50310099000
HEXAGON NUT M20X1,5 '98 (M20X1,5)

Узлы для 400 DUKE/ 20kW (930045) [EU] KTM
