Oil pump - Manifold

Oil pump - Manifold
Например: AP8510838
1
AP8510838
Vis
2
AP8206968
Vis (M6x22)
3
AP8206653
ipe d’admission
3
AP8206972
ipe d’admission
3
AP8206602
ipe d’admission
4
AP8206242
Reed valve fix.plate
5
AP8206300
Reed valve assy
6
AP8206303
Clutch cable anchor bridge
7
AP8206710
pipe 345 mm
7
AP8206975
pipe 710 mm
8
AP8206711
pc - Collier
9
AP8508669
4 pc - Dowel pin (D3x21,8)
10
AP8501467
pc - Seeger
11
AP8508872
ump gear Z=22
12
AP8206277
Rondelle
13
AP8206632
Oil pump shaft
14
AP8502665
O-Ring
15
AP8502562
Vis
16
AP8508863
Oil pump
16
AP8276028
Oil pump Mikuni
16
AP8508863
Oil pump
17
AP8508667
Cable adjuster rubber
17
AP8276026
Cable adjuster rubber
18
AP8206645
Oil pump cover
18
AP8276029
Oil pump cover
19
AP8206280
Vis
20
AP8508668
10 pc - Oil pipe grommet
20
AP8276025
Oil pipe grommet
21
AP8206631
pipe 190 mm
21
AP8206974
pipe 320 mm
22
AP8206342
Collier
23
AP8206181
Collier
