OIL PUMP - FILTER » LUBRICATION SYSTEM

OIL PUMP - FILTER » LUBRICATION SYSTEM
Например: 17420132A
1
17420132A
Pompe à huile
2
24711041A
Oil pump cover
3
77350712B
pc - Vis
4
85250261A
pc - Rondelle
5
25020302A
OIL PUMP BODY
6
77350678B
Vis
7
68010011B
2 pc - .WOODRUFF KEY 4X4X8
8
77151292B
.SCREW M8X40
9
85310021A
pc - Rondelle (spring)
10
77110518B
pc - Vis
11
85310041A
.SPRING WASHER 6 MM
12
17410041A
GEAR, OIL PUMP DRIVE
13
71010011A
SPINDLE, TAPER
14
78010181A
.BYPASS CAP
15
075949280
Dowel pin
16
22032083A
Rondelle
17
78020471A
Vis de vidange d'huile (Magnetic)
18
78710091A
Rondelle
19
066049800
OIL NET FILTER
20
44440039A
Filtre à huile
21
81510281A
BOLT UNION
22
88641321A
O-Ring
23
77910262A
.SCREW M12X1
24
88440421A
.SPRING RING
25
88450361A
pc - Seeger
26
067049310
BUSH
27
77911622A
5 pc - Vis
28
85211951A
Rondelle
29
59310181A
BY-PASS VALVE
30
79910551A
BYPASS SPRING
31
81510011A
NIPPLE
32
87510181A
OIL DELIVERY PIPE
33
78710051A
pc - Rondelle
34
77910861B
Vis (spec)
35
74140601A
2 pc - Collier
36
77150638B
pc - Vis
37
42020064A
10 pc - Rondelle (ALU)
38
78010371A
.THREADED PLUG M14X1.5
39
066549360
. NIPPLE
40
85250241A
Rondelle
