OIL PUMP - FILTER » LUBRICATION SYSTEM

OIL PUMP - FILTER » LUBRICATION SYSTEM
Например: 17420383D
1
17420383D
Pompe à huile
2
066070110
Oil pump cover
3
17410021A
GEAR, OIL PUMP DRIVE
4
066070065
GEAR, PUMP DRIVEN
5
25010021A
OIL PUMP BODY
6
77150678B
pc - Vis
7
68010011B
2 pc - .WOODRUFF KEY 4X4X8
8
77151292B
.SCREW M8X40
9
85310021A
pc - Rondelle (spring)
10
77110471A
pc - Vis
11
85310041A
.SPRING WASHER 6 MM
12
17410011A
PUMP GEAR T58
13
71010011A
SPINDLE, TAPER
14
742230574
.PIN, SPRING
15
075949280
Dowel pin
16
22032083A
Rondelle
17
78020471A
Vis de vidange d'huile (Magnetic)
18
78710091A
Rondelle
19
066049800
OIL NET FILTER
20
44440039A
Filtre à huile
21
81510281A
BOLT UNION
22
938232037
10 pc - O-Ring
23
77910262A
.SCREW M12X1
24
88440421A
.SPRING RING
25
88450361A
pc - Seeger
26
067049310
BUSH
27
067089350
. PLUG
28
42020064A
10 pc - Rondelle (ALU)
29
78010371A
.THREADED PLUG M14X1.5
30
85211951A
Rondelle
31
77911622A
5 pc - Vis
