NACELLE & HEADLAMP - FLHR & FLHRC

NACELLE & HEADLAMP - FLHR & FLHRC
1
787
SCREW, TRUSS HEAD, CROSS RECES
2
2647B
5 pc - SCREW, HEX SOCKET HEAD CAP
3
2806
Vis
4
2933
Vis
5
5210
NUT, WELL
6
6150W
Rondelle
7
6789
WASHER, #6 LARGE DIA.
8
7889
NUT, KEPS, #6-32
9
7888A
NUT, FLANGE, SERRATED
10
11489
TRIM, HEADLAMP HOUSING
11
14019-83A
LABEL, ON/OFF SWITCH
12
56914-08
INSERT, HANDLEBAR COVER
13
61081-92
KEY, HEAD COVER SET
14
NACELLE, right
14
67682-03B
NACELLE,LH-HDLAMP,CHRM
15
67668-05
MEDALLION, H/LAMP 7 IN
16
67712-83B
HEADLAMP DOOR, CHROME
17
67718-60A
Vis
18
67721-48
SCREW, HDLMP RET RING
19
67724-71
SCREW, HEADLAMP ADJUSTMENT
20
67726-08
RING ASSY. HEADLAMP
21
67728-02A
HEADLAMP BUCKET
22
67732-08
MOUNTING RING, HEADLAMP
23
67778-60A
SPRING, TOP
24
67782-60A
HEADLAMP BRACKET
25
COVER, handlebar (chrome)
26
67868-03
TRIM, NACELLE
27
68329-03
BULB,HB2/H4
28
68342-05A
LAMP ASY,7-IN,DOM
29
68390-05
HEADLAMP BOOT, 7 INCH DOM
30
70292-89
SOCKET HSG,4-PLACE
31
71310-94
TRIM ASY,FORK LOCK
32
KEY (specify key #)
33
71540-94B
FORK LOCK (REQ KEYCODE)
33
53571-03A
LOCK SET
33
53596-03A
LOCK SET
34
71522-08
TOGGLE SWITCH
35
72038-71A
SOCKET, TERMINAL
36
74408-08A
DRESS NUT
37
2934
SCREW, SHEAR HEAD
38
2935A
SCREW, SHEAR HEAD
39
9898
TERMINAL, FLAG
40
15346-98A
LABEL,FRT/FOG LAMP,HDI
40
14019-83A
LABEL, ON/OFF SWITCH
41
53438-92
BULB
42
68344-05A
LAMP ASY,7-IN,LH-DIP,HDI
42
REFLECTOR ASSEMBLY, right dip (HDI)
43
68359-05
WIRE HARNESS, JUMPER, POSITION
44
68380-05
BOOT
45
68653-05
SOCKET,POS BULB
46
71565-08
TOGGLE SWITCH, FOG/ILLUMN'TD
47
72253-94
TERMINAL, 18-20 GA
