Mudguards/Chainguard/Battery Box

Mudguards/Chainguard/Battery Box

Например: Rear Mudguard Assy

1

Rear Mudguard Assy

2

T3350004

Locknut, Flanged, M8 x 1.25

2 шт. в узле

3

T3205254

Bolt, HHF, Lghtd, M8 x20, Slv

2 шт. в узле

4

T3205066

Bolt, HHF, Lghtd, M6 x 20, Slv

6 шт. в узле

5

T3010702

Flanged Sleeve, 6.4 x 10 x 8.5

6 шт. в узле

6

T3020153

Grommet, 13 x 3 x 10

2 шт. в узле

7

3700009-T0301

Clip

2 шт. в узле

8

3700010-T0301

Clip cable

2 шт. в узле

9

2305220-T0301

Front mudguard

9

2305212-T0301

Front mudguard

9

2305218-T0301

Front mudguard

9

2305213-T0301

Front mudguard

10

Bracket lh

11

T2020091

Bracket, RH

12

T3331111

Screw, Pan/Hd, Tx, M6 x 55, Sl

2 шт. в узле

13

T3331041

Screw, Pan/Hd, Tx, M6 x 25, En

2 шт. в узле

14

3330504-T0301

Screw, M6 x 20

2 шт. в узле

15

2058000-T0301

Chainguard

16

3330504-T0301

Screw, M6 x 20

2 шт. в узле

17

2300341-T0301

Shield

18

2300340-T0301

Shield

19

T2307377

Pop Rivet, Dia 4.8

4 шт. в узле

20

Washer

21

2500060-T0301

Battery box

22

2070710-T0301

Bracket

23

T3203222

Bolt, HHF, M6 x 12, Slv

2 шт. в узле

24

T3331044

Screw, Pan/Hd, Tx, M6 x 16, Sl

25

T3551283

Washer, M10, 10.5x18x1.6, Slv

26

T3020153

Grommet, 13 x 3 x 10

2 шт. в узле

27

T2501740

Battery Strap

28

T2300335

Mudguard extension

29

T3330941

Screw, But/Hd, Skt, M5 x 16, S

3 шт. в узле

30

T3350010

Locknut, Flgd, M5

3 шт. в узле

31

3550060-T0301

Washer, Plastic, 14.3 x 2.0

2 шт. в узле

32

Foam Pad, 30 x 90 x 13

33

T2300359

Mudguard flap

34

T3300062

Pop Rivet

3 шт. в узле

35

T3330061

Rivet

5 шт. в узле
