MAIN WIRING HARNESS (1 OF 2)

MAIN WIRING HARNESS (1 OF 2)
Например: 70139-05
0
70139-05
WIRE HARNESS, MAIN, XL
1
9825
TERMINAL, RING, 1/4
2
9898
TERMINAL, FLAG
3
9838
TERMINAL, RING, .25 STUD
4
9937
TERMINAL .25 FASTON 18-14GA
5
10065
CABLE STRAP
6
10177
CABLE STRAP, PLUG IN
6
CLAMP, pan (not illustrated)
7
PUSH RIVET
8
31601-04
RELAY, SPST, SEALED
9
53486-85
T/PAK BACKREST PROTECTIVE PAD
10
71510-04
HOUSING, IGNITION SWITCH
11
71550-94
DECAL, IGNITION SWITCH
12
71552-94
IGNITION SWTICH FACENUT
13
72033-93
SOCKET, TERMINAL
14
72100-04
HOUSING CONNECTOR
15
72103-94BK
SEALED PIN HOUSING, BLACK, 3-P
16
72106-94BK
SEALED PIN HOUSING, BLACK, 6-P
17
72119-94BK
SEALED SOCKET HOUSING, BLACK,
18
72124-94GY
SEALED PIN HOUSING, GRAY, 4-PI
19
72139-94GY
SEALED SOCKET HOUSING, GRAY, 1
20
72143-94
SECONDARY LOCK, 3 PIN
21
72144-94
SECONDARY LOCK, 4 PIN
22
72146-94
SECONDARY LOCK, 6 PIN
23
72159-94
SECONDARY LOCK, 12-SOCKET
24
72163-94
PLUG, PIN CONNECTOR, RUBBER
25
72164-94A
PLUG, 4-WAY PIN CONNECTOR, RUB
26
72179-94
INTERNAL SEAL 12 CIRCUIT
27
72190-94
STAMPED & FORMED PIN
28
72191-94
STAMPED AND FORMED SOCKET
29
72195-94
SEAL PIN,4-WAY RECEPTACLE
30
72199-94
CONNECTOR ANCHOR,T-STUD
31
72213-94
TERMINAL, 18-20 GA. FEMALE
32
72214-94
CABLE SEAL
33
72230-98
SOCKET HOUSING, 3 WAY
34
72231-98
SECONDARY LOCK, 3 WAY
35
72234-94
CONNECTOR, SEALED, 2-POSITION
36
72236-94
FEMALE TERMINAL, 14-16 GA
37
72238-94
SECONDARY LOCK
38
72260-04
HOUSING, 1 WAY FEMAIL
39
72289-04
TERMINAL, FEMALE, 10-12 AWG
40
72291-94
TERMINAL, 56 SERIES, 14-16GA
41
72295-94
HOUSING, .187 TERM
42
72312-04
HOUSING 3 WAY SOCKET
43
72326-95
TERMINAL, ECM
44
72330-95
Fusible (15A)
45
72405-98BK
PUSH-ON WIRE ASSY, RIGHT ANGLE
46
72427-00
TERMINAL, .187, 22-16 GAUGE
47
72431-00
FUSE MOUNTING BLOCK, TYPE 1
