Main Frame & Fittings

Main Frame & Fittings
Например: T2074506
1
T2074506
Frame Assy, World
1
T2074507
Frame Assy, Americas
1
T2074508
Frame Assy, Canada
1
T2074525
Frame Assembly, World
1
T2074526
Frame Assembly, Americas
1
T2074527
Frame Assembly, Canada
2
T3202098
Bolt, TX, M10 x 60, Slv
2 шт. в узле
4
T3202110
Bolt, TX, M10 x 270
5
T3350005
Locknut, Flgd, M10
3 шт. в узле
5
T3350250
Locknut, Flanged, M10
3 шт. в узле
6
T2077810
Spacer, Engine Mount
2 шт. в узле
7
T3555029
Washer, 10.5 x 23 x 2
2 шт. в узле
8
T2078991
Frame Adjuster, M18
2 шт. в узле
9
T3555009
Washer, 10.5 x 21 x 1.22
10
T3800091
Bearing, Sac
2 шт. в узле
11
T2304321
Protector, Heelguard
12
T3600267
O Ring, ID 26.65 x Dia 2.62
2 шт. в узле
13
T3451260
Firtree, 5 x 11mm, Blk
6 шт. в узле
15
T2078915
Bung, Frame Cross Beam, LH
16
T2078916
Bung, Frame Cross Beam, RH
17
T2071688
Engine Dresser Bar Assy, LH
17
T2071680
Spares Kit, Dresser Bars, LH &
18
T2071689
Engine Dresser Bar Assy, RH
18
T2071680
Spares Kit, Dresser Bars, LH &
19
T3205254
Bolt, HHF, Lghtd, M8 x20, Slv
6 шт. в узле
20
T2071686
Engine Dresser Bar Assy, Centre
21
T3331042
Screw, Pan/Hd, Tx, M6 x 12, En
2 шт. в узле
22
T3450675
Bung, Hole Dia 12, Black
6 шт. в узле
