LUBRICATING SYSTEM|Engine|38

LUBRICATING SYSTEM|Engine|38
1
77338005100
Filtre à huile
2
07703305178
O-Ring
3
77338041200
OIL FILTER COVER 08
4
0025060166
Vis
5
0799060000
TAB WASHER DIN6799-RS 6,0
6
58038007755
STOP DISK 8,1 X 15 X 0,5
7
77038001200
OIL PUMP GEAR
8
0025050146S
Hex coll. screw M5x14 ISA30 self-locking
9
A48038003000
Oil pump cover
10
59038011112
Pompe à huile (12 mm)
11
A48038002000
OIL PUMP SHAFT
12
0402251980
NEEDLEROL.DIN5402 NRA 2,5X19,8
13
0402251180
NEEDLE ROLLER DIN5402 2,5X11,8
14
0402041580
needle roller NRB 4x15.8 G2
15
61238011100
ROTOR SET 22MM
16
0770440020
O-RING 44,00X2,00 VITON
17
79238004000
OIL PUMP COVER LEFT
18
58038022000
Rondelle
19
58030021100
Vis de vidange d'huile
20
07701250151
O-RING 12,5X1,5 VITON V75
21
59038016200
Filtre à huile
22
0770020170
O-Ring
23
59038017100
Vis de vidange d'huile
24
0401090003
BALL DIN5401-9
25
A48038026000
Compression spring
26
0025050146S
Hex coll. screw M5x14 ISA30 self-locking
27
78036024000
PLUG SCREW SAS M12X1,5
28
59030023100
Dowel, 6x8x11.5
29
0770012021
O-RING 12X2 VITON GREEN
30
0900001600200
Screw plug M16x1.5
33
A48038006033
OIL PUMP INTERMEDIATE GEAR 31T
34
0988121805
SHIM WASHER DIN0988-12X18X0,50
35
0471120010
retaining ring DIN 471 12x1
36
77038013100
BUSHING PIN
37
77238061050
AXIAL-CIRCLIP
38
0018050103S
Oval head screw DIN 7985-M5x10-8.8
99
79438015010
OILFILTER SERVICEKIT SX-F

Узлы для FC 450 (F2401W1) [] HUSQVARNA 2023 Offroad
