LUBRICATING SYSTEM|Engine|38

LUBRICATING SYSTEM|Engine|38
Например: 79238002100
1
79238002100
Oil pump shaft
2
59038011112
Pompe à huile (12 mm)
3
61238111000
ROTOR-SET CPL. 22MM
4
77038001100
OIL PUMP GEAR 14T 08
5
79238004000
OIL PUMP COVER LEFT
6
79238003000
OIL PUMP COVER RIGHT
7
0025060166
Vis
8
0984050143S
CYL. SCREW DIN6912 M5X14 8.8
9
77238061050
AXIAL-CIRCLIP
11
77338041200
OIL FILTER COVER 08
12
77338005100
Filtre à huile
14
0402251980
NEEDLEROL.DIN5402 NRA 2,5X19,8
15
0402251180
NEEDLE ROLLER DIN5402 2,5X11,8
16
0402041580
needle roller NRB 4x15.8 G2
17
79238006100
OILPUMP IDLER GEAR
18
0988121805
SHIM WASHER DIN0988-12X18X0,50
19
0471120010
retaining ring DIN 471 12x1
20
07703305178
O-Ring
21
59038017100
Vis de vidange d'huile
22
59038016200
Filtre à huile
23
07701250151
O-RING 12,5X1,5 VITON V75
24
0770020170
O-Ring
25
58038007755
STOP DISK 8,1 X 15 X 0,5
26
0799060000
TAB WASHER DIN6799-RS 6,0
28
0770440020
O-RING 44,00X2,00 VITON
30
0018050103
INT. TORX OVAL HEAD M 5X10 8.8
31
77038013100
BUSHING PIN
41
0401090003
BALL DIN5401-9
42
58038023300
PRESSURE SPRING L=25MM D=1MM
43
58038022000
Rondelle
44
78036024000
PLUG SCREW SAS M12X1,5
98
00050000083
OILFILTER-GASKET SET 350 SX-F
