LUBRICATING SYSTEM|Engine|38

LUBRICATING SYSTEM|Engine|38
Например: 76738051000
1
76738051000
Refroidisseur d’huile
4
79438006000M01
Cylinder pin
5
0799060000
TAB WASHER DIN6799-RS 6,0
6
58038007755
STOP DISK 8,1 X 15 X 0,5
7
79438001019M03
oil pump gear
8
0025060166S
Vis
9
79438003000M02
oil pump cover
10
77038011000
OILPUMP ROTOR 15MM G-164
11
79438002000M02
Oil pump shaft
12
0402251980
NEEDLEROL.DIN5402 NRA 2,5X19,8
13
0402251180
NEEDLE ROLLER DIN5402 2,5X11,8
14
0402041580
needle roller NRB 4x15.8 G2
15
61238011100
ROTOR SET 22MM
16
0770440020
O-RING 44,00X2,00 VITON
17
79438004100
OIL PUMP COVER
18
58038022000
Rondelle
19
58030021100
Vis de vidange d'huile
20
07701250151
O-RING 12,5X1,5 VITON V75
21
59038016200
Filtre à huile
22
0770020170
O-Ring
23
59038017100
Vis de vidange d'huile
24
0401090003
BALL DIN5401-9
25
79438026000M01
Compression Spring
27
78036024000M01
Locking screw oil system
28
78138015001
OIL SCREEN CPL.
29
0770012021
O-RING 12X2 VITON GREEN
30
0770125015
O-Ring
31
0770170200
O-Ring (17x2)
32
0770017025
O-RING 17X2,5
33
79438001033M04
Intermediate gear 33 Z
34
0988162205
THRUST WASH. DIN0988-16X22X0,5
35
0471150010
CIRCLIP DIN0471-15X1
36
0984050143S
CYL. SCREW DIN6912 M5X14 8.8
37
07700390261
O-Ring (39,34x2,62)
38
76738050000
Oil adapter
39
76738035000
Tube f/ oil adapte
40
0025050166
Vis
41
07703305178
O-Ring
42
0770012021
O-RING 12X2 VITON GREEN
49
76438034000
OIL JET
50
0603100141
Rondelle
51
76738030000
Hollow screw M10x1 wrench size10
52
59038017100
Vis de vidange d'huile
53
76438041000
COVER OIL FILTER 1
54
76438043000
HOUSING OI FILTER
55
76438042000
COVER OIL FILTER 2
56
83538005000
Filtre à huile
57
41001052000
Damper (D=12 mm)
58
60035001000
Vis (spec)
59
76438053000
OIL PIPE L=105MM
60
76438054000
OIL PIPE L=615MM
61
76438055000
OIL PIPE L=696MM
62
76311093200
CABLE TIE 200MM
63
76711094010
Plug-in base
64
0021060003
Rondelle
