LUBRICATING SYSTEM

LUBRICATING SYSTEM
Например: 61038081233
1
61038081233
OIL TANK CPL.
2
58030020100
Bouchon de remplissage d’huile
3
0770191015
O-Ring
4
0912050103
AH SCREW DIN0912-M 5X10
5
60038082050
ANGLE CONNECTOR BRACKET PANEL
6
60038082000
ANGLE CONNECTOR LC8 03
7
0770080020
O-RING 8X2 SILICONE
8
58030021100
Vis de vidange d'huile
9
58038022000
Rondelle
10
60038061203
PREFORMED HOSE D9X3,5
10
60038064000
T-CONNECTOR W. REDUCTION RING
11
60038061044
OIL PIPE "B"
12
0770090021
O-RING 9X2 VITON
13
61038034000
OIL HOSE PIPE A 05
14
60038060044
OIL PIPE "A"
15
00050256706
VARIABLE ONE-EAR CLAMP 25,6MM
16
00050198706
VARIABLE ONE-EAR CLAMP 19,8MM
17
0025060166
Vis
18
60038017000
OIL SCREEN FINISHED 03
19
60038018000
GASKET FOR OIL FILTER HNBR 03
20
60038024000
PLUG 10MM LC8 03
21
0770110021
O-RING 11X2 VITON
22
60038037000
RETAINING PLATE 2 LC8 03
23
60038036000
RETAINING PLATE 1 LC8 03
24
0912060203
AH SCREW DIN0912-M 6X20
25
60038083000
SCREW OIL TANK FIXING 03
26
77205068000
DAMP. COMPON. BLACK
27
60035001000
Vis (spec)
28
41001052000
Damper (D=12 mm)
29
54603048100
clip nut M6
30
00050185706
VARIABLE ONE-EAR CLAMP 18,5MM
31
61011093000
WIRING HOLDER 05
33
61038084100
OIL RISING PIPE CPL.
34
0603082121
SEAL RING CU DIN7603- 8X12X1
35
58038029000
BANJO BOLT M8X1
36
60038059130
OIL TANK BREATHING HOSE R/S
37
00049160121
CLAMP STD DN16
38
60038059083
OIL TANK BREATHING HOSE L/S
39
61038085000
STICKER "OIL LEVEL" 05
40
60038010000
PRESSURE PUMP CASE 03
41
60038026000
CONTROL SPRING LC8 3,5 BAR
42
60038128000
CONTROL PISTON
43
0988060121
WASHER 6X12X1 HRC 40-45
44
0472012010
CIRCLIP DIN0472 J12
45
60038011000
ROTOR-SET PRESSURE PUMP 03
46
60038002000
OIL PUMP SHAFT 03
47
0402041580
needle roller NRB 4x15.8 G2
48
60038001024
OIL PUMP GEAR 24-T 03
49
0799080000
retaining washer DIN 6799 - 8
50
60038007010
washer 10x16x0.5
51
60038009000
ROTOR-SET 19MM 03
52
60038008000
SUCTION PUMP CASE 03
53
0402040980
NEEDLE ROL.DIN5402 NRB 4X9,8
54
0770133024
O-RING 13,3X2,4 VITON
55
60038016000
OIL SCREEN 03
56
0025060406
Vis
57
0025060206
Vis
59
0770010010
o-ring 10.00x1.00 NBR70
60
60030065100
OIL INJECTION TUBE GEAR 05
61
61338015200
Filtre à huile
62
0025060106
Vis
64
60038060102
OIL TANK VALVE CPL.
65
0760101844
Joint
