LEG SHIELD

LEG SHIELD
1
5D8-F8311-00-P8
LEG SHIELD 1
1
5D8-F8311-00-LK
EG SHIELD 1
1
5D8-F8311-00-P7
LEG SHIELD 1
2
5D8-F118N-00
LABEL
3
90167-04X00
pc - Vis
4
90109-06X05
Болт
656 ₽/шт
5
5D8-F835U-00-P8
ANEL 1
5
5D8-F835U-00-LK
PANEL 1
5
5D8-F835U-00-P7
ANEL 1
6
90167-04X00
pc - Vis
7
5XL-F831A-00
BODY, COWLING
8
5DS-F8317-00
pc - Nut
9
90167-04X00
pc - Vis
10
90159-06X00
Vis
11
5DS-F8371-00
amper
12
5DS-F8312-00
LEG SHIELD 2
13
90167-04X00
pc - Vis
14
5DS-F839L-11
ID 2
15
9290L-05200
pc - Rondelle
16
90183-05813
pc - Nut
17
5D8-F1708-00
LOCK ASSY 2
18
4MJ-F1791-10
Nut
19
5DS-F839K-00
LID 1
20
90167-04X00
pc - Vis
21
90465-05X00
CLAMP
22
5NR-F837L-00
PANEL, CONSOLE 1
23
5DS-F8317-00
pc - Nut
24
90167-04X00
pc - Vis
25
5DS-F8385-01-PS
COVER, LOWER
25
5DS-F8385-01-LK
COVER, LOWER
25
5DS-F8385-01-PR
COVER, LOWER
26
5DS-F8317-00
pc - Nut
27
5DS-F8343-10
GUARD, STONE
28
9890M-06016
Винт
149 ₽/шт
29
5XL-F171L-00-PJ
MOLE, SIDE COVER 1
29
5XL-F171L-00-LK
MOLE, SIDE COVER 1
29
5XL-F171L-00-PH
MOLE, SIDE COVER 1
30
90167-04X00
pc - Vis
31
5DS-F8317-00
pc - Nut
32
5DS-F171M-03-PS
OLE, SIDE COVER 2
32
5DS-F171M-03-LK
OLE, SIDE COVER 2
32
5DS-F171M-03-PR
OLE, SIDE COVER 2
33
90167-04X00
pc - Vis
34
5DS-F8317-00
pc - Nut
35
5DS-F8368-00
Emblem
36
5DS-F837N-00
GRILL, AIR INTAKE 1
37
9890M-06016
Винт
149 ₽/шт
38
90387-068J5
Втулка
175 ₽/шт
39
90167-04X00
pc - Vis
40
5DS-F415E-10
Autocollant

Узлы для YP125E MAJESTY 125 (5D85) 2009 YAMAHA Majesty 125 YP 125 (VIN: VTLSE068)
