INTAKE » UNCLASSIFIED

INTAKE » UNCLASSIFIED
Например: 44220471B
1
44220471B
AIRBOX
2
76410861A
Damper
3
85020021A
.HOOK
4
69923771A
RH-LH AIR BOX KIT
5
77450021B
pc - Vis
6
69923761A
RH-LH AIR BOX COVER KIT
7
42620031A
Filtre à air (RH)
8
85210751A
pc - Rondelle
9
73640401A
.SHEAR RIVET
10
78810451A
. RIGHT GASKET
11
87720021A
HOSE, DRAIN
12
76410281A
Damper
13
80210191A
PIPE
14
70010291A
Damper
15
77210081A
Vis (spec)
16
77210171A
pc - Vis (spec)
17
87620021A
. PIPE
18
800050450
. CLAMP 22 MM
19
58510171A
VENT TANK
20
85040821A
.THREADED INSERT
21
82710992A
PLATE
22
77210551A
pc - Vis (M5x0.8x16)
23
77250968B
pc - Vis (M6x10)
24
800050454
.CLAMP 25MM
25
87610531A
BREATHER PIPE
26
74150271B
Collier
27
59310031B
Oil breather valve
28
066049920
Gasket
29
69923761A
RH-LH AIR BOX COVER KIT
30
42620021A
Filtre à air (LH)
31
69923771A
RH-LH AIR BOX KIT
32
78810441A
. LEFT GASKET
33
44210481A
IRBOX
34
79110431A
Gasket
35
79110441A
Gasket
36
79110451A
Gasket
37
76410251A
. FAIRLEAD RUBBER RING
38
59011551A
.PIPE
39
59011561A
.PIPE
40
59011471B
.PIPE
41
79110411B
.AIRBOX-TANK GASKET
42
77911941B
Vis (spec)
43
76410271B
.FAIRLEAD RUBBER RING
44
28740241A
Collier
45
05610221A
INSERT
