GEAR SHIFTER

GEAR SHIFTER

Например: 609

1

609

ROLL PIN

2

856A

SCREW, HEX SOCKET HEAD CAP

3

3784

SCREW, SET

4

3909

SCREW, HEX CAP SEMS

5

3275

SCREW, HEX SOCKET HEAD CAP

6

4192

SCREW, CAP HEX, 86 SOFTAIL, EX

7

4387

5 pc - Vis

8

5826

Entretoise

9

5977

Rondelle

10

6497HW

Rondelle

11

7041

Rondelle (Lock)

12

7904

ACORN NUT, 86+SOFTAIL(EXCEPT F

13

9837

Roulement

14

11150

RETAINING RING

15

11191

25 pc - O-Ring

16

11319A

RETAINING RING

17

11342

RETAINING RING, CAMSHAFT

18

12045

OIL SEAL

19

33301-00A

PILLOW BLOCK ASSY, SHIFTER CAM

20

33304-00

PILLOW BLOCK ASSY , SHIFTER CA

21

33364-00A

DETENT FOLLOWER, TRANSMISSION

22

33374-00

SPRING, DETENT ARM

23

33375-00A

SPRING SLEEVE, DETENT ARM

24

33376-00

SCREW, PIVOT, DETENT ARM

25

SHIFTER CAM

26

33660-90B

SHIFT LEVER

27

33708-94

BEARING, SHIFTER ASSY

28

SHIFTER LEVER

29

SHIFTER LINKAGE KIT, w/ 6, 8, 12, 33, & 46

30

33849-97

SHIFTER LEVER

31

33888-99

ROD END, SELF-ALIGNING 86+SOFT

32

33889-99

NUT, ROD END, 86 SOFTAIL, EXCE

33

33890-99A

COVER, SHIFTER ROD, 86 SOFTAIL

34

34088-87A

SHIFTER FORK SHAFT

35

34064-00C

SPRING, SHIFT RETURN

36

34191-79E

SHIFTER FORK, 1ST & 2ND GEAR

37

34193-79E

SHIFTER FORK, 3RD & 5TH GEAR

38

34195-79E

SHIFTER FORK, 4TH GEAR

39

SHIFTER PEG KIT, w/ 7, 11, 43, 44, & 45

40

34972-02B

SHIFTER PAWL ASSEMBLY

41

34977-02A

SPRING, RATCHET ARM

42

34978-00A

CENTERING PIN

43

42534-82

Vis

44

PEG, shift lever

45

INSERT, shifter peg

46

ROD ASSEMBLY, shifter link

47

33874-05

ROD, SHIFTER LINKAGE
