GEAR BOX » UNCLASSIFIED

GEAR BOX » UNCLASSIFIED
1
025147054
pc - . THRUST WASHER 25.2X32.5X1.2
2
14910331A
MAIN SHAFT 13T
3
067016150
.THRUST WASHER 0.5 MM
4
70140051A
Needle bearing
5
17211101A
DRIVING GEAR 5TH SPEED
6
85610011A
.THRUST WASHER 0.5 MM
7
067016145
.SPRING RING
8
17211091A
GEAR, 3RD PINION 21/23T
9
17211111A
GEAR, 6TH DRIVE NT:26
10
17212581A
DRIVING GEAR 2ND
11
71310141E
THRUST WASHER 20.3X32X1.6
12
449A0433A
Pignon avant (Z=15)
13
82610111A
Plate, drive sprocket fixing
14
77210551A
pc - Vis (M5x0.8x16)
15
71312661A
THRUST WASHER 17.3X31X3.15
16
85610311A
.THRUST WASHER 0.5 MM
17
764020002
Needle bearing
18
17211121A
DRIVEN GEAR 1ST SP.
19
067016155
.THRUST WASHER 1 MM
20
17211161A
DRIVEN GEAR 5TH SPEED T22
21
17211151A
DRIVEN GEAR 4TH SPEED T:26
22
17212541A
DRIVEN GEAR 3RD SPEED
23
17211171A
DRIVEN GEAR 6TH SPEEDT:24
24
17214521A
DRIVEN GEAR 2ND SPEED
25
14910341A
DRIVEN SHAFT
26
067016170
.THRUST WASHER 0.8 MM
27
15021011A
COMPLETE MAIN SHAFT
28
15021021A
DRIVEN SHAFT

Узлы для Monster 400 DUCATI 2006
