Главная Каталог товаров DUCATI EPC 2004 DUCATI Superbike 999 RS DUCATI 2004 FUEL PUMP » TANK/SEAT

FUEL PUMP » TANK/SEAT

FUEL PUMP » TANK/SEAT
Например: 88641181A
1
88641181A
O-Ring
2
42540091A
Filtre à carburant
3
59011441A
FILTER/PUMP PIPE
4
81410732A
UNION
5
060992225
O-Ring
6
59310231A
VALVE
7
79911171A
Spring
8
81410942A
.UNION
9
85211951A
Rondelle
10
74941108B
5 pc - Nut
11
77940391A
Vis
12
81410741B
UNION, QUICK-COUPLING
13
83012523B
SKID PLATE
14
82140011A
.PIN
15
79940021B
Spring
16
58810051A
2 end part
17
82712781A
PLATE
19
77940401A
Vis
20
81411721A
UNION
21
42020064A
10 pc - Rondelle (ALU)
22
59032531A
. PIPE
23
71610011A
SPACER
24
81410991A
UNION
25
42710011A
.FILTER
26
43040051A
Pompe à essence
27
82910112A
LOWER PUMP SUPPORT
28
85250261A
pc - Rondelle
29
81411041A
UNION
30
28740241B
pc - Collier (16,8 mm)
31
42740021A
DEGASER
32
938232021
O-Ring
33
74840321A
Nut
34
74950011B
Nut
35
742230574
.PIN, SPRING
36
82910101A
UPPER PUMP HOLDER
37
71610821A
BUSH
38
51012691A
PUMP WIRING
