FRONT & REAR SUSPENSION

FRONT & REAR SUSPENSION
Например: 3D6-F2187-00
1
3D6-F2187-00
GUIDE, CHAIN
2
1D4-F2225-00
Vis
3
1D4-E4775-00
Nut
4
1D4-F2141-00
SHAFT, PIVOT
5
3D6-F2110-00
Rear arm
6
1D4-F2143-00
Nut
7
1D4-F2142-00
WASHER, SHAFT
8
3D6-F1400-00
ENGINE BRACKET COMP.
9
1D4-F1293-00
Nut
10
13C-F1481-00
BOLT, ENGINE MOUNTING 1
11
1D4-F2149-00
Rondelle
12
3D6-F2210-00
Amortisseur arrière
13
1D4-F2241-00
Vis
14
1D4-F2242-00
Vis
15
1D4-F2251-00
NUT 1
16
1D4-F2243-00
WASHER 1
17
3D6-F3100-00
RONT FORK ASSY
18
3D6-F2403-00
UNDER BRACKET COMP
19
1D4-F3181-00
Vis
20
3D6-F3102-00
RONT FORK ASSY (L.H)
21
1D4-F2441-00
SPRING, FRONT FORK
22
1D4-F2480-00
Joint d'huile de fourche
23
1D4-F3156-00
pc - CLIP, OIL SEAL
24
1D4-F3144-00
ork dust seal
25
3D6-F3126-00
TUBE, OUTER (LEFT)
26
3D6-F3151-00
SPRING, REBOUND
27
3D6-F3124-00
TUBE, INNER 1
28
3D6-F3171-00
PISTON, FRONT FORK
29
3D6-F3173-00
SPINDLE, TAPER
30
1D4-F3159-00
WASHER, SPRING, LOWER
31
3D6-F3181-00
Vis
32
1D4-F3158-00
GASKET
33
3D6-F3448-00
Entretoise
34
1D4-F3155-00
RING, FELT
35
1D4-F319U-00
CAP
36
1D4-F3147-00
O-Ring
37
3D6-F3103-00
RONT FORK ASSY (R.H)
38
1D4-F2441-00
SPRING, FRONT FORK
39
1D4-F2480-00
Joint d'huile de fourche
40
1D4-F3156-00
pc - CLIP, OIL SEAL
41
1D4-F3144-00
ork dust seal
42
3D6-F3136-00
TUBE, OUTER (RIGHT)
43
3D6-F3151-00
SPRING, REBOUND
44
3D6-F3124-00
TUBE, INNER 1
45
3D6-F3171-00
PISTON, FRONT FORK
46
3D6-F3173-00
SPINDLE, TAPER
47
1D4-F3159-00
WASHER, SPRING, LOWER
48
3D6-F3181-00
Vis
49
1D4-F3158-00
GASKET
50
3D6-F3448-00
Entretoise
51
1D4-F3155-00
RING, FELT
52
1D4-F319U-00
CAP
53
1D4-F3147-00
O-Ring
54
3D6-F311H-00
ORK, BOLT
55
1D4-F3150-00
OUTER NUT COMP.
56
1D4-F339Y-00
Roulement
57
1D4-F3527-00
SEAL, DUST 1
58
1D4-F3528-00
SEAL, DUST 2
59
1D4-F3453-00
NUT, FITTING 1
60
1D4-F3437-00
COVER, CROWN
61
3D6-F3435-00
CROWN, HANDLE
62
1D4-F3471-00
Vis
63
1D4-F3441-00
HOLDER, HANDLE UPPER
64
1D4-F3471-00
Vis
65
1D4-F5388-00
PULLER, CHAIN 1
66
1D4-F5379-00
BOLT, CHAIN PULLAR
67
1D4-F538E-00
NUT, ADJUSTING
68
3D6-F5875-00
HOLDER, BRAKE HOSE 1
69
1D4-F4177-00
Vis
70
1D4-E2456-00
Rondelle
71
13D-F1635-00
NUT, REAR FENDER
