FRONT FORK, TRIPLE CLAMP

FRONT FORK, TRIPLE CLAMP
0
54601390000
FORK PROTECTOION GUIDE R/S '96
0
54601391000
FORK PROTECTOR R/S MARZOCCHI96
1
7124729
* FORK LEGS CPL.
1
7124730
* FORK LEGS CPL.
1
7124731
* FORK LEGS CPL.
5
54601291000
FORK PROTECTOR L/S '96
6
54601290000
FORK PROTECTION GUIDE L/S '96
8
0025050206
Vis
9
0985050003
SELF LOCKING NUT DIN0985-M 5
10
0025050126
Vis
12
7520196
H H COLLAR SCREW M 6X25 WS=10
15
54601099000
Câble de compteur de vitesse
32
50201132044
BOT.FORK PLATE X=18MM/D=45MM
32
54601132044
BOTT.TRIPLE CLAMP X=16/D=45MM
33
54801133000
FORK TUBE L=244
34
50201134000
TOP FORK PLATE X=18MM/D=45MM
34
54601134000
% top triple clamp x=16mm/d=45
38
50301038000
HANDLEBAR CLAMP D=22MM 2001
43
50301036000
STEER.HEAD SCREW M20X1,5 WS=27
44
56401044000
* WASHER 21X38X3
53
0025080306
Vis
54
0015080353
Vis
57
0933070203
HH SCREW DIN0933-M 7X20
58
0934070003
HEXAGON NUT DIN0934-M 7
80
77701084000
O-RING SUPPORT W. SEALING LIP
81
54201081100
Cage à bille de direction
83
54601184000
STEARING HEAD GASKET TOP
86
54201086000
STEERING HEAD COVER
99
54212035000
RING WRENCH WS=32

Узлы для 250 EGS M/Ö 12KW (732660) [EU] KTM
