FRONT FORK DISASSEMBLED|Frame|01

FRONT FORK DISASSEMBLED|Frame|01
Например: 48602046S2
1
48602046S2
Axle clamp ri. with inner tube cpl.
2
48602045S2
Axle clamp le. with inner tube cpl.
3
0025080256
Vis
5
RP10033T
epair kit adjuster rebound red
6
48602052S
adjuster housing M20x1 cpl.
7
48601533S
PLUG M20 CPL.
8
48601574S6
Pistonrod D12 M9x1 L385 cpl.
9
48601501S3
Piston rod 12x470 cpl.
10
48602131S2
crew sleeve M35,5x0,8 cpl
11
48602138S2
crew sleeve M35,5x0,8 cpl.
12
48600578S
PRING REBOUND . SPRING GUIDE
13
48601820S
pring rebound spring guide
14
RP10035T
epair kit piston air fork
15
48602049S2
Basevalve cpl.
16
RP10029T
adjuster kit screw cap compression
17
48602048S2
crew cap M51x1,5 cpl.
18
48602047S3
crew cap M51x1,5 cpl.
19
00700007
Vis
20
48601494S
VALVE M8X1 INCL. SCREW CAP
21
48602148
Outer fork tube 49.13x567 dt54 db60
22
R14047T
Guide bushing set fork 48mm (48 mm)
23
RP10048T
Front fork revision kit
24
04100002
X-RING 26,57X3,53 FKM 80SH.
25
50180222
O-ring 4x1,5 NBR70
26
48602135S
Piston 33,6x35,4 cpl.
27
48601948
Fork protection ring 60,1mm
28
52000247
Sticker Warning
29
48602007
Stroke indicator 48mm red
30
52000235SET
ticker set XACT 5 AER CC 182.5x238
31
48602128
Nut M6 h5,4 SW10
96
T14034
Fuchs grease IPR (250g)
97
00062010053
spezial grease AER Fork 50g
98
48601166S1
FORK OIL SAE4 5L
99
RP10034T
Gasket kit air fork
