FRONT FORK DISASSEMBLED|Frame|01

FRONT FORK DISASSEMBLED|Frame|01
Например: 43570395S1
1
43570395S1
crew cap M46x1,5 cpl.
2
46811042
O-ring 40x2 NBR70 black
3
48600812ST
ADJUSTING KNOB + SCREW
8
48600481
Cross countersunk head screw M4x8
9
48600046
O-ring 3x1,5 NBR70
12
43570614E
Fork outer tube 44,14x510 dt49 db53 natu
13
43570099
Round-wire snap ring 53x2
15
43570618
Guide bushing 42x44x20
16
43570092
Supportwasher 45x52,5x1,5
17
43570623
Shaft seal SKF 43x52,9x11,4 black
18
43570008
Rondelle (Lock)
19
43570624
Dirt scarper SKF 43mm black
22
43570617
Guide bushing 42x44x20
24
43570396S
top 12,4x28,6x135 cpl.
30
48600695
Adjustment tube 6x442
31
48600694
Piston rod 12x476
33
48600277
Needle 4,5x43,6
34
48600298
O-ring 2x1,5 NBR70
35
48600444
Spring (5,4) 4-23 rebound
36
43570133
Preload bush 26,5x38x2,5
37
43570135
Preload bush 26x38x10
37
43570136
Preload bush 26,5x38x1,5
37
43570133
Preload bush 26,5x38x2,5
37
43570134
Preload bush 26x35x4
38
95010032S
PRING 3,4 N/MM SET D=4,4MM
38
95010033S
PRING 3,6 N/MM SET
38
95010031S
PRING 3,2 N/MM SET D=4,2MM
39
43570131
Spring retainer 33,5x38,2x3
41
48600430
Guide bushing 12x14x10
42
48600830S2
CREW SLEEVE M27X0,8 CPL.
43
48600299
O-ring 6x1,2 NBR70
44
48600511
Spring (13,9) 17-32 rebound
45
48600513
TAP REBOUND 07
46
48600525
Spring retainer 12,3x19x1,25 rebound
47
48600382
Spring (11,4) 0,4-8 valve
51
48600455
Piston ring 21x23x5
52
48600575
Piston 6,07x22,7x13
55
40540486
Nut M6x0,5 h6,5 WAF10 rebound
57
48600870
Tube 23x330
58
48600764
Adapter 23x28x70
59
43570023
O-ring 41x2 NBR70 siliconized yellow
60
43570559S1
AXLE CLAMP L/S + TUBE CPL.
61
43570558S1
AXLE CLAMP R/S + TUBE CPL.
63
48600885
Nut valve M6x0,5 h6,5 WAF17
64
48600202
Spring (8,5) l6,5 valve
69
48600586S3
Compression, cmpl.
71
48600047
Piston 6x27,8x9 compression
72
46811499
O-ring 21x2 NBR70
73
35480320
O-Ring (24x2)
76
48600049
O-ring 8x2 NBR70
81
48600004
Copper disc 29,5x33,5x1
82
48600141
Rubber cap 35x10 NBR80
83
T14034
Fuchs grease IPR (250g)
99
R511T
epair kit
