Главная Каталог товаров HUSQVARNA EPC 2014 HUSQVARNA Offroad HUSQVARNA 2014 TE 250 HQV (F2375N8) [US] HUSQVARNA 2014 Offroad FRONT FORK DISASSEMBLED|Frame|01

FRONT FORK DISASSEMBLED|Frame|01

FRONT FORK DISASSEMBLED|Frame|01
Например: 48601029S1
3
48601029S1
AXLE CLAMP R/S WITH INNER TUBE
4
48601028S1
AXLE CLAMP L/S WITH INNER TUBE
5
0025080256
Vis
6
48601008
Guide bushing 47x49x20
7
48601009
Guide bushing 48x52x12
8
48600013
Supportwasher 50x57,6x1,5
9
S604800001000C1
Oil Seal Ring 48X57,8X9,5 03
1 623 ₽/шт
10
48600070
Rondelle (Lock)
11
S604800000000C1
Fork dust seal
12
48600736
Fork outer tube 49,13x577 dt54 db60 natu
13
91410092S
PRING D43,8 L465 4,8N/MM SET
13
91410082S
PRING D43,8 L465 3,8N/MM SET
13
91410081S
PRING D43.8 L465 3.6N/MM SET
13
91410083S
PRING D43,8 L465 4,0N/MM SET
13
91410084S
PRING D43,8 L465 4,2N/MM SET
13
91410085S
PRING D43,8 L465 4,4N/MM SET
13
91410086S
PRING D43,8 L465 4,6N/MM SET
14
48600456
Washer 35x43x2,5 plastic
14
48600458
Washer 35x43x1,5 plastic
15
48601116S
CREW CAP M51X1,5 COMP. KPL
15
48601050S
CREW CAP M51X1,5 REB. KPL.
16
R14033
SCREW CAP SMALL PART KIT
17
48601031S
CARTRIDGE KIT
18
R14034
HYDROSTOP KIT
19
48601279S
BASE VALVE KIT
20
48601025S1
Check valve d21mm cpl.
21
R14035
SCREW SLEEVE KIT
22
48601123S
NEEDLE KIT
23
R14036
TAP KIT
24
48600382
Spring (11,4) 0,4-8 valve
25
48601054S
PISTON ROD CPL.
26
48601035S
PRING GUIDE CPL.
27
48601021S
Reservoir 36x74,5 cpl.
27
48601021S2
PRESSURE TANK L74,5 D36 S2 CPL
27
48601021S3
PRESSURE TANK L74,5 D36 S3 CPL
27
48601021S4
PRESSURE TANK L74,5 D36 S4 CPL
28
46811265
O-ring 2,2x1,6 Viton75 green
30
48601166S1
FORK OIL SAE4 5L
31
T14034
Fuchs grease IPR (250g)
99
RP10047T
EPAIR - KIT
