FRONT FORK DISASSEMBLED

FRONT FORK DISASSEMBLED
Например: 48602129S1
1
48602129S1
screw cap M51x1.5 rebound cpl.
2
48602129S2
crew cap M51x1.5 compression cpl.
3
48600048
O-ring 46x2 NBR70 siliconized yellow
4
48601931
Fork outer tube 19,13x515 dt54 db60
5
95010106S
Mainspring (44) 8,5-300 set fork
5
95010089S
Mainspring (44) 9,0-300 set fork
5
95010107S
Mainspring (44) 9,5-300 set fork
6
48600458
Washer 35x43x1,5 plastic
6
48600456
Washer 35x43x2,5 plastic
6
48600457
Preload bush 35x43x3,5
7
48602225S02
Cartridge 34x340 cpl. Right
8
48602225S03
Cartridge 34x340 cpl. Left
9
48601702
Shim 27,5x33x0,3
10
48601298
Spring retainer 27,08x43x45
11
48601986
Fork protection ring 60,1mm
12
48602007
Stroke indicator 48mm red
13
48601082S02
axle clamp right cpl. with innertube
14
48601081S02
axle clamp left cpl. with innertube
15
0025080206
Vis
16
00501020S1
AH SCREW M10X20 SET
17
52000209SET
ticker set APEX OC 90x40
94
48601166S1
FORK OIL SAE4 5L
95
T14034
Fuchs grease IPR (250g)
97
R14047T
Guide bushing set fork 48mm (48 mm)
98
RP10048T
Front fork revision kit
99
RP10021T
Adjuster kit screw cap
