Главная Каталог товаров KTM EPC 2021 KTM Street KTM 2021 Travel KTM 2021 Street 890 ADVENTURE R (F9703U7) [EU] KTM FRONT FORK DISASSEMBLED

FRONT FORK DISASSEMBLED

FRONT FORK DISASSEMBLED
Например: 48601952S1
1
48601952S1
axle clamp right d48 25mm cpl
2
48601951S1
axle clamp left d48 25mm cpl.
3
48601794
Outer tube L567 D54 / D60
4
91410142
Mainspring (44) 6,7-460 fork
4
91410162S
mainspring (44) 6.2-460 set fork
4
91410163S
mainspring (44) 7.2-460 set fork
5
48600458
Washer 35x43x1,5 plastic
5
48600456
Washer 35x43x2,5 plastic
5
48600457
Preload bush 35x43x3,5
6
48602028S4
screw cap M51x1,5 rebound cpl.
7
48602028S3
screw cap M51x1.5 compression cpl.
8
RP10021T
Adjuster kit screw cap
9
48600048
O-ring 46x2 NBR70 siliconized yellow
10
RP10048T
Front fork revision kit
11
R14047T
Guide bushing set fork 48mm (48 mm)
12
48600763S3
Tube L350 with screwsleeve and hole
13
48600763S4
Tube L350 with screwsleeve
14
48600430
Guide bushing 12x14x10
15
48601843S2
Tap compression cpl.
16
40540486
Nut M6x0,5 h6,5 WAF10 rebound
17
48602002S
Midvalve piston assembly d23
18
35480377
Spring (11,7) 1,5-8 valve
19
48600576
Tap 6x46 rebound
20
48600299
O-ring 6x1,2 NBR70
21
48601929S
rebound spring C60 cpl
22
48601922
spring support ring
23
48601096S
Needle 4,5x43,6 cpl.
24
48601558S
COMPRESSION ADJ. NEEDLE CPL.
25
48601923
Piston rod 12x501
26
48601924
Adjuster tube L=471.5
27
S228700003S0100
GasGas Stop 12,4x31,9x200,3 kpl.
28
48600163
Nut valve M6x0,5 h6,5 WAF17
29
48600202
Spring (8,5) l6,5 valve
30
48601934S
Piston 6x27,3x9 compression cpl.
31
48601921
Tap 6x42,5 base valve
32
04500003
O-RING 11X2,5 NBR 70 SH PTFE
33
48601702
Shim 27,5x33x0,3
34
0025080206
Vis
35
48602007
Stroke indicator 48mm red
36
48601986
Fork protection ring 60,1mm
37
48601976S
RingISK screw M10x25 with o-ring
38
35480085
O-ring 7x2 NBR70
39
52000281SET
sticker Xplor OC 100x46
98
T14034
Fuchs grease IPR (250g)
99
48601166S1
FORK OIL SAE4 5L
