FRONT FORK DISASSEMBLED

FRONT FORK DISASSEMBLED
Например: 48600811S
1
48600811S
Adjuster compression cpl.
2
48600526
Cross flat head screw M4x10
3
48600542
HS countersunk head screw M4x6
4
50180222
O-ring 4x1,5 NBR70
5
15080017
Silicon plug 60Sh
6
40140024
O-ring 43x2 NBR70 siliconized yellow
7
48600516E1
SCREW CAP L=125
8
48600514
Clamping ring bladder 11,31x22x7,5
9
48600281
Membrane 11,2x37x112
10
48600299
O-ring 6x1,2 NBR70
11
48600509
Tap 6x38 compression
12
48600047S
Piston 6x27,8x9 compression cpl.
13
46811499
O-ring 21x2 NBR70
14
48600202
Spring (8,5) l6,5 valve
15
48600163
Nut valve M6x0,5 h6,5 WAF17
16
40540486
Nut M6x0,5 h6,5 WAF10 rebound
17
48600455
Piston ring 21x23x5
18
48600575S
PISTON REBOUND + PISTON RING
19
48600382
Spring (11,4) 0,4-8 valve
20
48600576
Tap 6x46 rebound
21
48600578
Spring (13,9) 37-32 rebound
22
48600525
Spring retainer 12,3x19x1,25 rebound
23
48600444
Spring (5,4) 4-23 rebound
24
48600298
O-ring 2x1,5 NBR70
25
48600277
Needle 4,5x43,6
26
48600464
Piston rod 12x405
27
48600269
Adjustment tube 6x371
28
48600459
Lock nut M12x1 h23 WAF17
29
48600977S
PIN KIT
30
48600519E4
MEMBRANE HOLDER INKL. PIPE
31
48600512
Rondelle (Lock)
32
48601056
Spring retainer 13,5x21,9x2,65
33
48600829
Seal ring Freudenberg 12mm 85Sh violett
34
48600430
Guide bushing 12x14x10
35
48601055S
CREW SLEEVE M24,5X1 CPL.
36
48600297
CHECK VALVE STOP
37
48600446
Rondelle (Lock)
38
48600761
Fork outer tube 49,13x577 dt54 db60 bla
39
48600698
Fork protection ring 62,1mm
40
48600016
Round-wire snap ring 48x2
41
RP10048T
Front fork revision kit
42
48600577
Spring guide ring 27,08x32x9,5
43
48600520
Spring support ring 27,08x42x41
44
48600744
Guiding ring 39x44x8
45
48600458
Washer 35x43x1,5 plastic
45
48600457
Preload bush 35x43x3,5
45
48600456
Washer 35x43x2,5 plastic
46
91410030S
PRING 5,0 N/MM
47
R14047T
Guide bushing set fork 48mm (48 mm)
48
48601540S1
AXLE-CL. MA DISC BR+INNERT. LF
49
48601541S1
AXLE-CL. MA DISC BR+INNERT. RE
50
0025080256
Vis
51
48600275
Copper disc 20,5x26x1
52
48600301
O-ring 9,5x1,5 NBR70 yellow
53
46810811
O-ring 17x2 70 Sh NBR black
54
48600280E
Adjustment screw slot M20x1 l33 cpl.
55
48600141
Rubber cap 35x10 NBR80
97
48601166S1
FORK OIL SAE4 5L
98
T14034
Fuchs grease IPR (250g)
99
RP10046T
EPAIR KIT SEALS MXMA CC2011
