FRONT FORK DISASSEMBLED

FRONT FORK DISASSEMBLED
Например: 40540603
5
40540603
Steel ball d3
12
48600381E
OUTER TUBE L=577 D=54/60MM
15
48601009
Guide bushing 48x52x12
17
S604800001000C1
Oil Seal Ring 48X57,8X9,5 03
1 623 ₽/шт
18
48600070
Rondelle (Lock)
19
S604800000000C1
Fork dust seal
22
48601008
Guide bushing 47x49x20
23
48601052
INNER TUBE D=48 L=595
24
48600380S1
top 14,4x32,1x200 cpl.
30
48600092
ADJUSTMENT TUBE L=517MM
31
48600409
PISTON ROD D=14 L=551 M11X1
33
48600189
Needle 6x42,6 rebound
36
48600113
Washer 32x42x2,5 plastic
38
91410011S
PRING 3,6N/MM SET
38
91410012S
PRING 3,8N/MM SET D=4,9MM
38
91410013S
PRING 4,0N/MM SET D=5,0MM
38
91410014S
PRING 4,2N/MM SET D=5,0MM
38
91410015S
PRING 4,4N/MM SET D=5,1MM
38
91410016S
PRING 4,6N/MM SET
38
91410017S
PRING 4,8N/MM SET
42
48600383S
CREW SLEEVE M29,3X1 L=90 CPL.
43
48600239
O-ring 8x1,25 NBR70 siliconized
44
48600403
Spring (15) 12-34,5 rebound
45
48600203
Tap 6x45 rebound
49
43570120
Shim 8x18x0,10
49
48600215
Shim 8x20x0,10
49
48600216
Shim 8x22x0,10
49
48600218
Shim 8X11X0,40
49
48600357
Shim 8x11x0,10
50
40540400
Shim 6x12x0,10
50
40540401
Shim 6x14x0,10
50
40540402
Shim 6x16x0,10
50
40540403
Shim 6x18x0,10
50
40540414
Shim 6x16x0,25
50
40540415
Shim 6x18x0,25
50
40540447
Shim 6x10x0,30
50
40540450
Shim 6x9,5x0,30
50
48600116
Shim 6x24x0,10 delta
55
40540486
Nut M6x0,5 h6,5 WAF10 rebound
58
48600081
TUBE 29,3X1X390 D=8,5MM
60
48600860S
AXLE CLAMP L/S CPL.
61
48600861S
Axle clamp right cpl.
63
48600163
Nut valve M6x0,5 h6,5 WAF17
64
48600202
Spring (8,5) l6,5 valve
69
48600586S3
Compression, cmpl.
74
48600586S3
Compression, cmpl.
75
48600190
Needle 10x11,6 compression
82
48600141
Rubber cap 35x10 NBR80
83
48601166S1
FORK OIL SAE4 5L
85
48600075S
PRE-LOAD ADJUSTER CPL.(1 PC.)
87
48600481
Cross countersunk head screw M4x8
89
48600075
SCREW CAP M51X1,5
90
48600073S
ADAPTER ADJUST. KNOB + BUSHING
91
48600077
O-ring 26x2 NBR90
93
48600072
Locking nut M25x1 LH h7 WAF32
94
48600071
Carrier ring spring fork
98
T14034
Fuchs grease IPR (250g)
99
R14007
EPAIR-KIT GASKET 4860 MXMA 03
