Главная Каталог товаров KTM EPC 2004 KTM Street KTM 2004 Naked Bike KTM 2004 Street 640 DUKE II BLACK (9722D7) [GB] KTM FRONT FORK DISASSEMBLED

FRONT FORK DISASSEMBLED

FRONT FORK DISASSEMBLED
Например: 48600020S1
1
48600020S1
CREW CAP M51X1,5 CPL.
2
46810340
O-ring 45x2 NBR70 siliconized
3
48600018
Adjuster rebound
4
48600020S1
CREW CAP M51X1,5 CPL.
5
40540603
Steel ball d3
6
48600028
Spring (1,7) l7,9
7
48600044
O-ring 6x1,5 NBR70
8
48600058
Cross flat head screw M4x6
9
48600009
O-ring 3,7x1,6 NBR70
10
48600043
O-ring 12x1,5 NBR70
11
48600019
Tube tap d4x25
12
43570210
OUT.TUBE BLACK L=577MM D=54/57
15
43570618
Guide bushing 42x44x20 (43x47x12)
16
43570092
Supportwasher 45x52,5x1,5
17
43570623
Shaft seal SKF 43x52,9x11,4 black
18
43570008
Rondelle (Lock)
19
43570624
Dirt scarper SKF 43mm black
22
43570617
Guide bushing 42x44x20
23
43570222
INNER TUBE D=43MM L=550MM 04
24
43570142S1
HYDR.STOP L=200 D=27,5 CPL. 05
30
48600131
Adjustment tube 6x357
31
48600255
PISTONROD D=14MM L=391MM M11X1
33
48600189
Needle 6x42,6 rebound
34
48600046
O-ring 3x1,5 NBR70
35
48600033
Spring (7,2) 4-23 needle
37
48600053
Preload bush 26,5x42x1,5
37
48600036
Preload bush 42x26,5x2,5
37
48600037
Preload bush 26,5x42x5
37
48600038
Preload bush 26,5x42x10
38
95010018S
PRING 7,0 N/MM SET D=4,9MM
39
43570131
Spring retainer 33,5x38,2x3
42
48600200S1
CREW SLEEVE M29,3X1 L=65 CPL.
43
48600239
O-ring 8x1,25 NBR70 siliconized
44
48600261
REBOUND SPRING 34,5X15X11
45
48600203
Tap 6x45 rebound
47
35480377
Spring (11,7) 1,5-8 valve
49
48600062
CHECK VALVE 8X24X0,1
49
43570120
Shim 8x18x0,10
49
48600215
Shim 8x20x0,10
49
48600216
Shim 8x22x0,10
50
40540401
Shim 6x14x0,10
50
40540402
Shim 6x16x0,10
50
40540403
Shim 6x18x0,10
50
40541402
Shim 6x11x0,20
50
40540414
Shim 6x16x0,25
50
40541391
Shim 6x11x0,30
50
40540415
Shim 6x18x0,25
50
48600063
Shim 6x24x0,10
50
48600064
Shim 6x22x0,10
50
48600065
Shim 6x20x0,10
50
48600116
Shim 6x24x0,10 delta
51
48600060
Pistonring 26x28x5
52
48600042
Piston 6,05x27,65x12 rebound
55
40540486
Nut M6x0,5 h6,5 WAF10 rebound
58
48600133
TUBE 29,3X1X405 D=28MM
59
48600163
Nut valve M6x0,5 h6,5 WAF17
60
43570196
AXLE CLAMP L/S BLACK DUKE 2002
61
43570197
AXLE CLAMP R/S BLACK DUKE 2002
62
48600202
Spring (8,5) l6,5 valve
64
48600061
Shim 8x24x0,40
65
46811499
O-ring 21x2 NBR70
66
48600047
Piston 6x27,8x9 compression
67
48600177S
TAP COMPRESSION CPL.
68
43570180
O-RING NBR 15X1,5
69
43570175
SPRING RING 29,8X1,6
70
43570023
O-ring 41x2 NBR70 siliconized yellow
72
48600034
Adjustment screw slot compression
73
48600051
Rondelle (Lock)
74
48600049
O-ring 8x2 NBR70
75
48600190
Needle 10x11,6 compression
78
0912080303
Vis (M8x30)
79
46810146
Copperwasher 12x16x1,5
80
48600176
HH collar screw M12x1x23
90
48601166S1
FORK OIL SAE4 5L
99
R511T
epair kit
