FRONT FORK DISASSEMBLED

FRONT FORK DISASSEMBLED
Например: 40541269
1
40541269
SCREW CAP M49X1,5 COMP
2
40541273
SCREW CAP M49X1,5 REBOUND
3
40540026
O-ring 43x3 NBR70
4
40540470
SPRINGRETAINER D=47MM
5
40540492
Seal ring 14,1x22x4 90Sh
6
40541270
AIR ADJUSTING SCREW
7
40541246
TAP ADJ. REBOUND
8
43570091
OUTER TUBE L=577MM D=54/57MM
9
43570099
Round-wire snap ring 53x2
10
40541257
O-RING NBR 4X2
12
43570019
DU-BUSH 47 X 43 X 20
13
43570092
Supportwasher 45x52,5x1,5
14
43570009
OIL SEAL RING 43X52,5X7
15
50600083
TAP ADJ. COMPRESSION
16
96010045S
% spring 3,8 n/mm set d=4,75mm
16
96010046S
PRING 4,0 N/MM SET D=4,75MM
16
96010047S
PRING 4,2 N/MM SET D=4,9MM
16
96010048S
PRING 4,6 N/MM SET D=5,0MM
16
96010049S
PRING 4,8 N/MM SET D=5,0MM
16
96010050S
PRING 4,4 N/MM SET D=4,9MM
17
40540359
PRELOAD SPACER L=2,5MM
18
40540040
PRELOAD SPACER L=5MM
19
43570121
SPRING GUIDE TA
20
40540851
PISTON RING 5 X 1 X 62
21
43570617
Guide bushing 42x44x20
22
43570221
INNER TUBE D=43MM L=585MM
25
43570023
O-ring 41x2 NBR70 siliconized yellow
30
43570087
AXLE CLAMP L/S USD43 260MM '99
31
43570086
AXLE CLAMP R/S USD43 M8 '99
32
40541267
O-RING NBR 3X1
33
40541374
REBOUND NEEDLE D=4MM L=542MM
34
58038032100
SEAL RING 8 X 12 X 2
35
50600130
Vis
36
0025080306
Vis
37
40541373
PISTON ROD M9X1 L=528MM
38
40541376S
HYDR.STOP L222,5MM KPL. COMP.
40
48601166S1
FORK OIL SAE4 5L
41
40541346
Spring (11,2/12,6) 60-26 rebound
42
40541245
PISTON ROD TAP COMPRESSION
43
40541244
PISTON ROD TAP REBOUND
44
40541278
Spring (8,5) l6,5 valve
45
43570624
Dirt scarper SKF 43mm black
46
40540629
SPRINGRETAINER 22,1X35,6X2
47
40540487
Rubber pad 13x19,3x7 90Sh
48
40540434
Guide bushing 12x14x8
49
40541378
SCREW SLEEVE M24X0,8X56
50
40541236
TUBE 24X1,5X385
51
40541241
CHECK VALVE NUT M6X0,5
53
40540477
Shim 8x18x0,40
54
40540445
PISTON COMPRESSION MA
55
40540437
O-ring 15,6x1,78 NBR
56
40540401
Shim 6x14x0,10
56
40540402
Shim 6x16x0,10
56
40540403
Shim 6x18x0,10
56
40540404
Shim 6x12x0,15
56
40540409
Shim 6x14x0,20
56
40540411
Shim 6x18x0,20
56
40540449
Shim 6x9x0,30
56
40540774
Shim 6x18x0,10
56
40541383
Shim 6X11X0,10
57
40541242
TAP COMPRESSION
58
40541256
CIRCLIP 21X1,6
60
40541085
PISTON REBOUND W5
62
40540486
Nut M6x0,5 h6,5 WAF10 rebound
63
40540867
O-ring 3x2 NBR70
65
40541377S
HYDR. STOP L=222,5MM KLP. REB.
66
40541259
Rondelle (Lock)
67
40540296
Steel ball d4
68
40540472
Spring (2,3) l5,2
69
43570122
RING 28X38X1,5
70
43570093
Rondelle (Lock)
