FRONT FORK

FRONT FORK
Например: 5RW-F3102-10
1
5RW-F3102-10
ONT FORK ASSY (L.H) (LH)
1
49D-F3102-00
RONT FORK ASSY (L.H) (LH)
2
49D-F3110-00
INNER TUBE COMP.1
2
5KK-F3110-00
INNER TUBE COMP.1
3
49D-F3126-00
TUBE, OUTER (L.H)
3
5RW-F3126-10
TUBE, OUTER (L.H)
4
49D-F3145-00
Joint
4
5KK-F3145-00
OIL SEAL
5
49D-F3156-00
RING, SNAP
5
5KK-F3156-00
Seeger
6
49D-F3144-00
SEAL, DUST
6
5KK-F3144-00
Cover dust
7
49D-F3170-00
CYLINDER COMP., FRONT FORK
7
5KK-F3170-20
CYLINDER COMP., FRONT FORK
8
49D-F3151-00
SPRING, REBOUND
8
5KK-F3151-00
Spring
9
49D-F3173-00
SPINDLE, TAPER
9
5KK-F3173-00
SPINDLE, TAPER
10
49D-F3165-00
WASHER, FELT
10
5KK-F3165-10
Rondelle
11
49D-F3394-00
BOLT, SPECIAL
11
5KK-F3356-00
Vis
12
49D-F3141-00
SPRING, FRONT FORK
12
5KK-F3141-10
ork inner tube
13
49D-F3118-00
Entretoise
13
5RW-F3113-00
COLLAR
14
49D-F3147-00
O-Ring
14
5KK-F3147-00
O-Ring
15
49D-F3111-00
BOLT, CAP
15
5KK-F3111-00
Vis
16
49D-F3183-00
Seeger
16
5KK-F3183-00
Seeger
17
49D-F3154-00
CAP
17
5C2-F3154-20
AP
18
5RW-F3108-00
EMBLEM
19
49D-F3153-00
RING, SNAP
19
5KK-F3153-00
RING, SNAP
20
49D-F3103-00
RONT FORK ASSY (R.H) (RH)
20
5RW-F3103-10
ONT FORK ASSY (R.H) (RH)
21
49D-F3110-00
INNER TUBE COMP.1
21
5KK-F3110-00
INNER TUBE COMP.1
22
49D-F3136-00
TUBE, OUTER
22
5RW-F3136-10
TUBE, OUTER
23
49D-F3145-00
Joint
23
5KK-F3145-00
OIL SEAL
24
49D-F3156-00
RING, SNAP
24
5KK-F3156-00
Seeger
25
49D-F3144-00
SEAL, DUST
25
5KK-F3144-00
Cover dust
26
49D-F3170-00
CYLINDER COMP., FRONT FORK
26
5KK-F3170-20
CYLINDER COMP., FRONT FORK
27
49D-F3151-00
SPRING, REBOUND
27
5KK-F3151-00
Spring
28
49D-F3173-00
SPINDLE, TAPER
28
5KK-F3173-00
SPINDLE, TAPER
29
49D-F3165-00
WASHER, FELT
29
5KK-F3165-10
Rondelle
30
49D-F3394-00
BOLT, SPECIAL
30
5KK-F3356-00
Vis
31
49D-F3141-00
SPRING, FRONT FORK
31
5KK-F3141-10
ork inner tube
32
49D-F3118-00
Entretoise
32
5RW-F3113-00
COLLAR
33
49D-F3147-00
O-Ring
33
5KK-F3147-00
O-Ring
34
49D-F3111-00
BOLT, CAP
34
5KK-F3111-00
Vis
35
49D-F3183-00
Seeger
35
5KK-F3183-00
Seeger
36
49D-F3154-00
CAP
36
5C2-F3154-20
AP
37
5RW-F3108-00
EMBLEM
38
49D-F3153-00
RING, SNAP
38
5KK-F3153-00
RING, SNAP
39
2AD-F3340-00
UNDER BRACKET COMP
40
22F-23414-01
Шайба подшипника
811 ₽/шт
41
49D-F3346-00
Vis
41
5KK-F3346-00
Vis
42
49D-F3843-00
WASHER, PLAIN
42
5KK-F3165-00
Rondelle
43
5RW-F3317-00
HOLDER, CABLE
44
9890L-06012
Винт
85 ₽/шт
45
5RW-F5876-00
HOLDER, BRAKE HOSE 2
46
9580M-06012
Болт
133 ₽/шт
47
BP2-23412-00
Race, Ball 2
763 ₽/шт
48
BP2-23411-00
Race, Ball 1
1 213 ₽/шт
49
22F-2341E-00
Подшипник (сепаратор)
1 319 ₽/шт
50
3VP-23416-00
Крышка подшипника
270 ₽/шт
51
90179-25X00
Nut
52
90202-26X00
Шайба
149 ₽/шт
53
5DS-F3418-00
Шайба специальная
468 ₽/шт
54
5RW-H5111-00
EFLECTOR, FRONT 1
