Главная Каталог товаров YAMAHA EPC < 124 cm³ YAMAHA Booster 50 CW 50 YAMAHA CW50RS BOOSTER NEXT GENERATION (4TD1) 1996 YAMAHA Booster 50 CW 50 FRONT FORK

FRONT FORK

FRONT FORK
Например: 4TD-F3100-03
1
4TD-F3100-03
ront fork assy
2
4SB-F3396-00
Vis (spec)
2
4TD-F3153-00
Seeger
3
4SB-F3111-00
.BOLT, CAP
3
4TD-F3154-00
PLUG, INNER TUBE
4
4SB-F3153-00
.RING, SNAP
4
4TD-F3112-00
Rondelle
5
4SB-F3141-00
PRING, FRONT FORK
5
4TD-F3394-00
Vis
6
4SB-F332L-00
TUBE, INNER
6
4TD-F3136-00
UBE, OUTER (RIGHT)
7
4SB-F3144-00
.SEAL, DUST
7
4TD-F3126-00
UBE, OUTER (LEFT)
8
4SB-F319Y-00
.GUIDE PLUNGER
8
4TD-F3183-00
Seeger
9
4SB-F3151-00
PRING, REBOUND
9
4TD-F3147-00
O-Ring
10
4SB-F3183-00
eeger
10
4TD-F3111-00
Vis
11
4SB-F3354-00
TOPPER BOUND
11
4TD-F3144-00
ork dust seal
12
4SB-F3181-00
Vis
12
4TD-F3156-00
CLIP, OIL SEAL
13
4SB-F3385-00
WASHER, SPECIAL 1
13
4TD-F3145-00
Joint
14
4SB-F3147-00
O-Ring
14
4TD-F3141-00
SPRING, FRONT FORK
15
4SB-F330E-00
.DAMPER ASSY
15
4CU-F3165-00
Rondelle
16
4SB-F3165-00
.WASHER, FELT
16
4TD-F3181-00
Vis
17
4SB-F3117-00
.GUIDE, SPRING
17
4TD-F3110-00
INNER TUBE COMP.1
18
4SB-F3393-00
Nut (Spec.)
18
5BR-F3340-02
UNDER BRACKET COMP.
19
4SB-F3357-00
Nut
20
4SB-F3411-00
RACE, BALL 1
21
4SB-F3414-00
RACE, BALL 4
22
4SB-F3412-00
RACE, BALL 2
23
4SB-F3812-00
PLANE BEARING, STEERING
24
4SB-F3427-00
Rondelle
25
4SB-F3453-00
NUT, FITTING 1
25
3VL-H5111-00
REFLECTOR, FRONT 1
26
4SB-F5876-00
HOLDER, BRAKE HOSE 2
27
95817-06010
Болт
95 ₽/шт
30
4SB-F3340-00
UNDER BRACKET COMP.
31
4SB-F3124-00
TUBE, INNER 1
32
4SB-F3126-00
TUBE, OUTER (LEFT)
33
4SB-F3136-00
TUBE, OUTER (RIGHT)
33
3VL-H5111-00
REFLECTOR, FRONT 1
