Главная Каталог товаров YAMAHA EPC 125 cm³ - 349 cm³ YAMAHA FZ16 150 YAMAHA FZ16 21C5 2010 YAMAHA FZ16 150 FRONT FORK

FRONT FORK

FRONT FORK
Например: 21C-F3100-01
1
21C-F3100-01
RONT FORK ASSY
2
21C-F3102-01
.FRONT FORK ASSY (L.H)
3
21C-F3126-01
..TUBE, OUTER (LEFT)
4
21C-F3114-00
..GASKET
5
21C-F3111-00
..BOLT, CAP
6
21C-F3118-00
..SPACER
7
21C-F3149-00
..WASHER, SPRING UPPER
8
21C-F3141-00
..SPRING, FRONT FORK
9
21C-F3181-00
Vis
10
21C-F3158-00
..GASKET
11
21C-F3173-00
..SPINDLE, TAPER
12
4EB-23144-00
Уплотнение (пыльник)
1 971 ₽/шт
13
21C-F3156-00
..RING, SNAP
14
4EB-23145-01
Сальник
1 669 ₽/шт
15
21C-F3146-00
..WASHER, OIL SEAL
16
4FM-23125-40
Направляющая втулка, пера вилки 1
2 194 ₽/шт
17
21C-F3170-00
..CYLINDER COMP., FRONT FORK
18
21C-F3110-00
..INNER TUBE COMP.1
19
21C-F3103-01
.FRONT FORK ASSY (R.H)
20
21C-F3136-01
..TUBE, OUTER (RIGHT)
21
21C-F3114-00
..GASKET
22
21C-F3111-00
..BOLT, CAP
23
21C-F3118-00
..SPACER
24
21C-F3149-00
..WASHER, SPRING UPPER
25
21C-F3141-00
..SPRING, FRONT FORK
26
21C-F3181-00
Vis
27
21C-F3158-00
..GASKET
28
21C-F3173-00
..SPINDLE, TAPER
29
4EB-23144-00
Уплотнение (пыльник)
1 971 ₽/шт
30
21C-F3156-00
..RING, SNAP
31
4EB-23145-01
Сальник
1 669 ₽/шт
32
21C-F3146-00
..WASHER, OIL SEAL
33
4FM-23125-40
Направляющая втулка, пера вилки 1
2 194 ₽/шт
34
21C-F3170-00
..CYLINDER COMP., FRONT FORK
35
21C-F3110-00
..INNER TUBE COMP.1
36
21C-F3340-00
.UNDER BRACKET COMP.
37
5YY-F3462-00
SEAL, DUST
38
5KA-F3411-00
RACE, BALL 1
39
21C-F3346-00
Vis
