FRONT FORK

FRONT FORK
Например: 52S-F3100-12
1
52S-F3100-12
RONT FORK ASSY
1
52S-F3100-03
RONT FORK ASSY
2
52S-F3102-01
RONT FORK ASSY (L
2
52S-F3102-10
RONT FORK ASSY (L.H)
3
52S-F3126-00
TUBE, OUTER (LEFT)
3
52S-F3126-10
TUBE, OUTER (L.H)
4
52S-F3110-00
INNER TUBE COMP.1
5
52S-F3171-00
PISTON, FRONT FORK
6
52S-F3157-00
RING, PISTON
7
52S-F3141-00
PRING, FRONT FORK
8
52S-F3145-00
Joint
9
52S-F3156-00
RING, SNAP
10
52S-F3144-00
ork dust seal
11
52S-F3125-00
METAL, SLIDE 1
12
509-23158-L0
Прокладка
366 ₽/шт
13
5LK-F3356-01
Болт
562 ₽/шт
14
52S-F3173-00
PINDLE, TAPER
15
52S-F3151-00
PRING, REBOUND
16
52S-F3147-00
O-Ring
17
52S-F3111-00
BOLT, CAP
18
52S-F3103-01
RONT FORK ASSY (R
18
52S-F3103-10
RONT FORK ASSY (R.H)
19
52S-F3136-00
TUBE, OUTER (RIGHT)
19
52S-F3136-10
TUBE, OUTER
20
52S-F3110-00
INNER TUBE COMP.1
21
52S-F3171-00
PISTON, FRONT FORK
22
52S-F3157-00
RING, PISTON
23
52S-F3141-00
PRING, FRONT FORK
24
52S-F3145-00
Joint
25
52S-F3156-00
RING, SNAP
26
52S-F3144-00
ork dust seal
27
52S-F3125-00
METAL, SLIDE 1
28
509-23158-L0
Прокладка
366 ₽/шт
29
5LK-F3356-01
Болт
562 ₽/шт
30
52S-F3173-00
PINDLE, TAPER
31
52S-F3151-00
PRING, REBOUND
32
52S-F3147-00
O-Ring
33
52S-F3111-00
BOLT, CAP
34
52S-F3340-02
UNDER BRACKET COMP
35
52S-F3346-00
Vis
36
52S-F3462-00
EAL, DUST
37
52S-F3411-00
RACE, BALL 1
38
52S-F3472-00
Protector
525 ₽/шт
39
52S-F3411-00
RACE, BALL 1
40
52S-F341E-00
RETAINER, BALL BEARING
41
52S-F3412-00
RACE, BALL 2
42
90179-30800
Гайка
1 224 ₽/шт
43
90202-30235
Шайба
159 ₽/шт
44
52S-F3418-00
Washer, Special
318 ₽/шт
45
52S-F3415-00
COVER, BALL RACE 1
46
52S-F3317-00
HOLDER, CABLE
