FRAME|Frame|03

FRAME|Frame|03
Например: 5540300130028
1
5540300130028
Frame 554R4 white
2
2500300201033A
Rear frame top
3
25003002020
SUBFRAME L/S
4
25003002130
SUBFRAME RIGHT
5
0035080206S
HCS M8x20 TX45
6
55403013000
ENGINE BRACE LEFT 17
7
55403014000
ENGINE BRACE RIGHT 17
8
0035080156S
AH-COLLAR SCREW M8X15 TORX45
9
79607012000
TANK REST RUBBER
10
58111076000
CABLE SUPPORT KHS NR.150-47610
11
0019080306S
COUNTER-SUNK SCREW ISA45 M8X30
12
50335030001
PVC-HOSE 6X9
13
50303089000
ANGLE PIECE '97
14
54310086100
SELF LOCKING NUT M10 CU WS=14
15
77203014000
engine brac.scr. M10x115
16
47106003160
quick release rubber grommet
17
0017060205
Vis
18
0025080306
Vis
19
0025060406
Vis
20
0125060003
WASHER DIN0125-A 6,4
21
79003040100
Foot grid left 2016
22
79003041000
FOOTREST R/S 2016
23
0125100003
washer DIN 125 A 10.5
24
79003044000
FOOTREST SPRING R/S 2016
25
54803044000
PIN FOR FOOT PED 51.5X9.8 MM
26
79003045000
FOOTREST SPRING L/S 2016
27
0094032250
PIN DIN 0094-3.2X25 NIRO
28
79003040133
Footpegs left+right cpl. 16
29
0035080206S
HCS M8x20 TX45
30
7900309400033
Frame Protection Set Black
3 492 ₽/шт
31
78105081010
SCREW TORX M5X10
32
54803092060
BUSH F. FRAME PROTECTION 03
33
44011076305
CABLE TIE 300/4,8MM BLACK
34
44011076140
CABLE TIE 140/2,5MM BLACK
98
79003053010
CHAIN SLIDING KIT BELOW CPL.16
99
55403096010
SPROCKET COVER KIT
