Главная Каталог товаров HUSQVARNA EPC 2018 HUSQVARNA Offroad HUSQVARNA 2018 TC 125 (F2101R0) [] HUSQVARNA 2018 Offroad FRAME|Frame|03

FRAME|Frame|03

FRAME|Frame|03
Например: 5040300110028
1
5040300110028
Frame 125/150 SX white
2
2500300201033A
Rear frame top
3
25003002020
SUBFRAME L/S
4
25003002130
SUBFRAME RIGHT
5
0035080206S
HCS M8x20 TX45
6
50403013100
Motor bracket left
7
50403014100
Motor bracket right
9
79007012000
TANK REST RUBBER
11
0019080306S
COUNTER-SUNK SCREW ISA45 M8X30
12
55007016001
PVC-HOSE 7X10 PER METER
13
50303089000
ANGLE PIECE '97
14
54310086100
SELF LOCKING NUT M10 CU WS=14
15
77203014000
engine brac.scr. M10x115
16
47106003160
quick release rubber grommet
17
0025080356
Vis
18
0025080306
Vis
19
0025060406
Vis
20
0125060003
WASHER DIN0125-A 6,4
21
79003040000
FOOTREST L/S 2016
22
79003041000
FOOTREST R/S 2016
23
0125100003
washer DIN 125 A 10.5
24
79003044000
FOOTREST SPRING R/S 2016
25
54803044000
PIN FOR FOOT PED 51.5X9.8 MM
26
79003045000
FOOTREST SPRING L/S 2016
27
0094032253
PIN DIN0094-3,2X25 STEEL
28
79003040133
Footpegs left+right cpl. 16
29
0035080206S
HCS M8x20 TX45
30
7900309400033
Frame Protection Set Black
3 492 ₽/шт
31
78105081010
SCREW TORX M5X10
32
54803092060
BUSH F. FRAME PROTECTION 03
33
44011076305
CABLE TIE 300/4,8MM BLACK
34
44011076140
CABLE TIE 140/2,5MM BLACK
35
0025080166S
Vis
98
79003053010
CHAIN SLIDING KIT BELOW CPL.16
99
50403096010
SPROCKET COVER KIT
