FRAME|Frame|03

FRAME|Frame|03
Например: 8130360110028
1
8130360110028
FRAME 450/501 FE USA 2014
2
8130300211030
SUB FRAME UPPER PART CPL. 14
3
8130300222030
SUB FRAME L/S cpl.
4
8130300213030
SUB FRAME R/S CPL. 2014
5
78903013000
REINFORCING
6
60011093075
RUBBER CABLE TIE 75MM 03
7
77207012000
TANK REST RUBBER
8
59001037000
Vis (spec)
9
58111076000
CABLE SUPPORT KHS NR.150-47610
11
0934080003
Nut
12
77036079000
CYLINDER HEAD SCREW 05
14
0035080206S
HCS M8x20 TX45
15
56530079000S
Hh Collar Screw M8X44 Ws13
184 ₽/шт
16
47106003160
quick release rubber grommet
17
81303002011
SPACER BUSHING 12X9X6,2
18
0019080306S
COUNTER-SUNK SCREW ISA45 M8X30
19
0035080306S
Vis (M8x30)
25
06923080003
Nut
26
54310086100
SELF LOCKING NUT M10 CU WS=14
27
0025080306
Vis
29
0025060306
Vis
36
78003040050
FOOTREST L/S 08
40
78003041050
FOOTREST R/S 08
41
54803044000
PIN FOR FOOT PED 51.5X9.8 MM
42
54603041000
FOOTREST SPRING L/S & R/S
43
0125100003
washer DIN 125 A 10.5
44
0094032253
PIN DIN0094-3,2X25 STEEL
45
78003040033
FOOTREST L/S + R/S CPL. 09
46
50303089000
ANGLE PIECE '97
47
55007016001
PVC-HOSE 7X10 PER METER
50
78103096000
Guard chain sliding shoe
59
77203053000
CHAIN SLIDER LOWER PART CPL.
64
77203053010
CHAIN SLIDING KIT BELOW CPL.11
99
78103096010
SPROCKET COVER KIT
