FRAME

FRAME
Например: 79703101100EB
1
79703101100EB
Frame 797T1
2
79103002100
Subframe
3
77303139000
BLIND RIVET NUT EM6-60LF/HX
4
0019080206S
Vis (Flat M8x20)
5
79003003000
Vis (spec)
6
79503113100
Engine brace left 450
7
79503114100
Engine brace right 450
8
0035080206S
HCS M8x20 TX45
9
79607012000
TANK REST RUBBER
10
58111076000
CABLE SUPPORT KHS NR.150-47610
14
54310086100
SELF LOCKING NUT M10 CU WS=14
15
59003013000
ENGINEBRAC.SCREW M10X123 WS=13
16
60011093075
RUBBER CABLE TIE 75MM 03
17
79103002010
Rear frame bit
18
0025080306
Vis
19
0025060356
Vis
20
0125060003
WASHER DIN0125-A 6,4
21
79603040000
FOOTREST L/S EXC 2017
22
79603041000
FOOTREST R/S EXC 2017
23
0125100003
washer DIN 125 A 10.5
24
79003044000
FOOTREST SPRING R/S 2016
25
54803044000
PIN FOR FOOT PED 51.5X9.8 MM
26
79003045000
FOOTREST SPRING L/S 2016
27
0094032253
PIN DIN0094-3,2X25 STEEL
28
79603040033
FOOTREST-SET
29
0025050106
HH collar screw M5x10 TX30
30
54803092060
BUSH F. FRAME PROTECTION 03
31
44011076305
CABLE TIE 300/4,8MM BLACK
32
44011076140
CABLE TIE 140/2,5MM BLACK
33
7910309410030
Frame protection set
34
79003002080
BLIND RIVET NUT M6 KNURLED
35
59001037000
Vis (spec)
36
0934080003
Nut
37
79711013010
Cable bracket d8
38
79111013010
Cover control head sheet
39
79711013000
Cable holder throttle cable guide
40
0035080156S
AH-COLLAR SCREW M8X15 TORX45
41
0081050181
SCREW FOR PLASTIC K50X18 T20
98
79003053010
CHAIN SLIDING KIT BELOW CPL.16
99
79403096010
SPROCKET COVER KIT
