FRAME

FRAME
Например: 95803001044C1
1
95803001044C1
Frame jet black
2
95803039000
Front footpeg bracket, right
3
95803038000
Front footpeg bracket, left
4
95803139050
Front heel protector right
5
95803138040
Front heel protector left
6
95803041133
Footpeg, front right, cmpl.
7
95803040050
Footpeg tread, front left
8
93003054000
Pin footrest pivot black
9
J125080005
WASHER M8
10
J094020186
pin cotter-dia. 2.5xl 18
11
90103038002
Nut (M10x1,25)
12
95803038010
Entretoise
13
95804070000
Guard chain sliding shoe
15
93008020060
Screw M6X1X9
16
J025080246
Hex collar screw, M8x23.5
17
95803001072
seat support side panel right cpl.
18
95803001071
seat support side panel left cpl.
19
95803001081
seat support cross connection front
20
95803001082
seat support cross connection rear
21
J025060122
Hex collar screw M6X12
22
95803001088
Bushing
23
95803040010
Damper, front right
24
95803041010
Damper, front left
25
95803044010
Retaining bracket, damper
26
J910000800500
NUT NYLOC-M5X0.8XHT. 4.5XCL6XBLK
27
J910001001000
NUT HEX FLANGED
28
J900001013500
BOLT SOCKET M10X1.25
29
J125100009
Washer M10
31
93303006000
Engine brace right
32
93303005000
Engine brace left250/390
33
95808005000
Mask support pipe, right
34
95808006000
Mask support left
35
J031080146
screw button head-m8x1.25xl14xbl
36
93014017000
Rubber bushing
37
J025102656
Vis
40
95807012000
Tank support rubber
41
90103007000
Bolt Socket Head M8
42
95803039010
Distance sleeve
43
90103042000
footrest return spring
44
J770009015
O-RING 9X1,5
47
90808043000
Vis (spec)
48
95814010040
Wheel spindle mask support
49
90108023100
Clip
50
J125080006
Washer M8
51
J912080251
Hexagon screw M8X25
52
J125100002
Washer, M8
